56
Additionally Required Materials / Zusätzlich erforderliche Materialien / Matériaux
supplémentaires requis / Materiales adicionales necesarios / Materiais Adicionais
Necessários / Extra benodigde materialmen / Materiali aggiuntivi necessary / Materiały
wymagane dodatkowo / Další požadované materiály / Ytterligare materialkrav /
Materiale suplimentare necesare /
/ Yderligere
nødvendige materialer /
/ Täiendavad vajalikud
materjalid / Muut vaaditut materiaalit / Potrebni dodatni materijali / További szükséges
anyagok / Papildomos reikalingos medžiagos / Papildus vajadzīgie materiāli /
Dodatočne požadované materiály / Dodatno zahtevani materiali / Ayrıca Gerekli
Malzemeler / Materiais Adicionais Necessários /
No. Required Material Type Conductor Cross-section
1 PV cable
Dedicated PV wire
withstand voltage 600 V
4 mm²
2 Communication cable Network cable CAT5e 0.2 mm²
3 Additional PE cable
Conventional yellow and
green wire
4 mm²
• Grid Cable and Micro-breaker recommended
Model
X1-Hybrid-
3.0-D
X1-Hybrid-
3.7-D
X1-Hybrid-
5.0-D
X1-Hybrid-
5.0K-D
X1-Hybrid-
6.0-D
X1-Hybrid-
7.5-D
Three-core
copper wire
4-6 mm² 6-8 mm² 8-10 mm² 8-10 mm² 8-10 mm²
Micro-
breaker
32 A 40 A 50 A 50 A 50 A
Model
X1-Hybrid-
3.0-M
X1-Hybrid-
3.7-M
X1-Hybrid-
5.0-M
X1-Hybrid-
6.0-M
X1-Hybrid-
7.5-M
Three-core
copper wire
3-4 mm² 3-4 mm² 4-6 mm² 4-6 mm² 4-6 mm²
Micro-
breaker
25 A 25 A 32 A 32 A 32 A
• EPS (Off-grid) Cable and Micro-breaker recommended (apply to version D/M)
Model X1-Hybrid-3.0 X1-Hybrid-3.7
X1-Hybrid-5.0
X1-Hybrid-
5.0K-D
X1-Hybrid-6.0 X1-Hybrid-7.5
Two-core
copper wire
3-4 mm² 3-4 mm² 4-6 mm² 4-6 mm² 4-6 mm²
Micro-
breaker
25 A 25 A 32 A 32 A 32 A
• Lead-acid battery breaker recommended (apply to version D/M)
Model X1-Hybrid-3.0 X1-Hybrid-3.7
X1-Hybrid-5.0
X1-Hybrid-
5.0K-D
X1-Hybrid-6.0 X1-Hybrid-7.5
Voltage
Nominal voltage of DC breaker should be larger than maximum voltage of
battery.
Current 32 A
To Next Page
