SolaX Power X1-Hybrid-3.7-D Installation Manual

57
Mechanical Installation / Mechanische Installation / Installation mécanique /
Instalación mecánica / Instalação mecânica / Mechanische installatie / Installazione
meccanica / Instalacja mechaniczna / Mechanická instalace / Mekanisk installation
/Instalare mecanică /

/ Mekanisk installation /


/ Mehaaniline paigaldus / Mekaaninen asennus / Mehanička ugradnja /
Mechanikai telepítés / Mechaninis montavimas / Mehāniskā uzstādīšana / Mechanická
inštalácia /Mehanska namestitev / Mekanik Kurulum / Instalação Mecânica /

* The installation height of the inverter needs to consider the height of the stacked battery.
1
223 mm
54 mm
4 5
ST6
320 mm
2 3
Ø
10 drill
Depth: >80 mm
6
M5
1.2±0.1 N·m

SolaX Power X1-Hybrid-3.7-D Specifications

General

Brand	SolaX Power
Model	X1-Hybrid-3.7-D
Category	Inverter
Language	English
