4 3 2 Compliance and Safety Symbols. .
Electrical shock!
There are residual voltages in the PV inverter It needs 10 minutes.
to finish discharge.
10min
The PV inverter must not be touched when in operation Its.
enclosure and heat sinks are extremely hot.
Electrical shock! This part is charged Only qualified and / or trained.
electrical technicians are allowed to perform operations on the inverter.
If the inverter service life has expired dispose it in accordance with,
local rules for disposal of electrical equipment waste Do not dispose.
the PV inverter with household garbage.
Safety symbol Description
According to installation position, one kinds of physical installation are described below in detail:
Support-mounting.
Basic Requirements
a The inverter is protected to IP65 and can be installed indoors or outdoors. .
b The installation method and position must be appropriate for the weight and dimensions of.
the inverter.
c Do not install the inverter in a place where personnel are likely to come into contact with its.
enclosure and heat sinks because these parts are extremely hot during operation.
d Do not install the inverter in an area that stores flammable or explosive materials. .
a The ambient temperature must be below 50 which ensures the inverter’s optimal. ℃
operation and extends its service life.
Installation Environment Requirements
4 4 1 Determining the Installation Position. .
4 4 Installation Requirements.
The PV inverter is compliant with TUV.
