THERMOCUBE 200/300/400 THERMOELECTRIC CHILLER MANUAL 52-11300-1
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590 19
TELEPHONE: (845) 296-1300 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM VERSION M28
SECTION 7
T
HERMOCUBE OPTIONS ____________________________________________
7.1 THERMOCUBE OPTIONS AND PART NUMBER
ThermoCube P/N: 10 – CCC – PP – FF – X – YY – OO
Cooling Pump Fan Power Fittings Other
Capacity Type Type Cord Options
CCC = Cooling Capacity (choose one):
CCC
Description
200
200 W @ 20°C in 20°C ambient air
300
300 W @ 20°C in 20°C ambient air
400
400 W @ 20°C in 20°C ambient air
300A
300 W inert gas temperature control
(No pump, No tank, Includes -LT
400AC
400 Watts air conditioner from 20°C house
chilled water. (No pump, No tank)
PP = Pump Type (choose one):
PP
Description
-1D
>1 lpm @ 35 psig diaphragm
(1 year warranty)
-2D
>1.5 lpm @ 35 psig diaphragm
(1 yearr warranty)
-3D
>3 lpm @ 30 psig diaphragm pump
(1 year warranty) , Requires 3/8” fittings
-1G
>1 lpm @ 35 psig magnetic drive gear, low
vibration with stainless steel head
-2G
>2 lpm @ 35 psig magnetic drive gear, low
vibration
-3GXX
>3 lpm @ 30 psig magnetic drive gear, low
vibration (XX = adjusted flow rate: XX=20 for
2 lpm, XX=10 for 1 lpm, XX=15 for 1.5 lpm
etc.) or XX=RF for 3 lpm with run / fill
-1C
~1 lpm @ 17 psig, ~2 liter/min @ 15 psig
centrifugal
-1CL
~1 lpm @ 12 psig, ~2 liter/min @ 10 psig
centrifugal
YY = Inlet/Outlet Fitting Options:
YY
Description
Std
John Guest 1/4” x 1/4” Bulkhead
-J2
John Guest 3/8 x 3/8” Bulkhead
-CP
1/4” CPC shut off valve coolant
-CP2
3/8” CPC shut off valve coolant
-CPM
1/4” CPC metal
-SW
1/4” Swagelok kit
-S2
3/8” Swagelok kit
-FN
1/4” Female NPT Bulkhead
OO = Other Options:
OO
Description
-R2
RS232 interface controller, improved
-EF
5 micron external liquid filter
-AF
External air intake filter
-SS
Stainless steel tank and stainless steel plumbing
(Only available with gear pump)
-ST
Stainless steel tank
-PT
Preset control temperature: (Input temp:___ °C)
-LT
Low temperature (<5°C) operation)
-HT
High temperature up to 65 °C
(60°C max for Centrifugal pumps)
-DC
Dry contact alarm signals
-VD
Vibration dampening material added
-AR
Auto restart – software
-DI
DI water compatible
-FL
Set up for Fluorinert or Galden
-PA
Set up for PAO
-###
Custom engineered special (CES), sequential
number assigned by Engineering
X = Power Cord (select one)
X
Country / Region
Part No.
-1
USA/Canada
22-22333-1
-2
Europe
22-22332-2
-3
Japan
22-22333-3
-4
UK
22-22333-4
-5
Israel
22-22800-1
-6
Australia
22-23213-1
-7
Korean
22-23526-1
-8
China (3 prong)
22-23661-1
-9
NEMA 6-15 208 US Straight
16-23918-1
-10
NEMA L6-15 208 US Twist
16-23918-2
-11
Brazil
22-25122-1
-12
India/South Africa 6A (Type D)
22-26025-1
-13
India/South Africa 15A (Type M)
22-26025-2
FF = Fan Type (choose one):
FF
Description
Blank
Standard fan noise <63 dBA @ 1m
-QF
Quiet Fan (no longer available)
-VS
Variable speed fan, noise
49 dBA to 63 dBA @ 1m
