SECTION 3
H
OOK UP _______________________________________________________
Figure 3A
Figure 3B
Figure 3C
Process Fluid Supply
(¼" push push-in-fittings)
On/Off Switch
Signal Connector
9-Pin D-sub
Fill Cap
Display Screen
Controller Input Buttons
Handle
Power Inlet Module
IEC 320 power inlet module with two 5X20
fuses
Optional 5-micron particle filter
Fasten the filter-mounting bracket
via the four screws located here
