6.4.3 Standard No.
The screen shows the reference standard of the Inverter (see Figure 6.11).
Standard: G83/2
Figure 6.11 Example of Standard of the Inverter
6.4.4 Version
The screen shows the model version and the software version of the Inverter
(see Figure 6.12).
Model: 08
Software Version: D20001
Figure 6.12 Model Version and Software Version
6.4.5 Communication Data
The screen shows the internal data of the Inverter (see Figure 6.13), which is for service
technicians only.
01-05: 01 25 E4 9D AA
06-10: C2 B5 E4 9D 55
Figure 6.13 Communication Data
6.5 Advanced Settings - Technicians Only
Select Advanced Settings from the Main Menu to access the following options:
1. Select Standard
2. Grid ON/OFF
3.Clearing Energy
6. Operation 6. Operation
NOTE:
To access to this area is for fully qualified and accredited technicians only.
For Technicians only.
.23. .24.
This function is used to select the grid's reference standard (see Figure 6.14).
YES=<ENT> NO=<ESC>
Standard: G83/2
Figure 6.14
NOTE:
This function is for technicians use only.
NOTE:
Before to using this function, please set "GRID OFF" to stop inverter (refer
to Section 6.5.2).
Press the UP/DOWN keys to select the standard (AS4777, VDE4105, UL1741, G83/2 (for
1-3.6kW models), G59/3 (for 4-5kW models) and “User-Def” function). Press the ENTER
key to confirm the setting. Press the ESC key to cancel changes and returns to previous
menu.
Selecting the “User-Def” menu will access to the following submenu (see Figure 6.15),
NOTE:
The inverter is customized according to the local standard before shipping
to the customer. The " User-Def" function can be only used by the service
engineer and must to be allowed by the local energy supplier.
Figure 6.15
Press the UP/DOWN keys to scroll through items. Press the ENTER key to edit the highlighted
item. Press the UP/DOWN keys again to change the setting. Press the ENTER key to save the
setting. Press the ESC key to cancel changes and returns to the previous menu.
6.5.1 Selecting Standard
OV-V: 262V
UN-V: 210V
OV-V: 240---270V
UN-V: 180---210V
OV-G-F: 50.3---52.0Hz(60.3—62.0Hz)
UN-G-F: 47.0---49.5Hz(57.0—59.5Hz)
Below is the setting range for “User-Def”. Using this function, the limits can be changed
manually.
