Starting / Stopping the engine
ENGLISH 14
7. Starting / Stopping the engine
7.1 Half throttle start position
A) Models with a "loop" handle (104L and 107L)
• Slide the stop switch (1) into the operating
position.
• Grip the handle; the safety locking key (3) is
activated via the grip area, which also enables
throttle lever (2) to be regulated.
• Press throttle lever fully down.
• Press the half throttle lock (4), and let the
throttle lever return, whilst holding the half
throttle lock in.
B) Models with a "bike" handle (107B)
• Grip the handle; the safety locking key (3) is
activated via the grip area, which also enables
throttle lever (2) to be regulated.
• Press throttle lever fully down.
• Whilst holding the throttle lever down, move
stop switch (1) towards "Start"
( ), and
release the throttle lever.
The part throttle stop is cancelled by brief
operation of the throttle control. The stop switch on
the bike handle then jumps to the central position
Î operating position.
7.2 Choke and primer
Adjust choke as follows:
• With a cold engine, position choke lever (7) up
towards "Close"
.
• With a warm engine, position choke lever (7)
down.
When first starting or if the fuel tank has been
completely drained and has been refilled, press
primer (8) several times (at least 5x) until the fuel
is visible in the plastic bulb.
Fig. 14
Fig. 13
Fig. 12
