Specification
ENGLISH 7
2. Specification
Engine type SOLO single cylinder two-stroke engine
Engine capacity cm
3
25
Engine power kW at rpm 0,7 / 7500
Max. permissible speed rpm
no load with cutter
8200±100
Medium idling speed rpm 2800±100
Fuel tank capacity l 0,4
Fuel mix ratio: with "SOLO 2T engine oil"
with other two-stroke oils
1:50 (2%)
1:25 (4%)
Carburettor All-position diaphragm carburettor with primer
and integrated fuel pump
Air filter Foam filter
Ignition Electronically controlled magneto ignition,
maintenance free
Weight, w/o shield and cutter kg 4,3
Drive shaft – property / diameter mm Flexible / 6,2
Shaft tube – material / diameter Ø mm Aluminium / 25
Dimensions Height / Width / Length mm 32 / 33 / 159
In determining the following values regarding the acceleration of vibrations and sound, the different
operating conditions were weighted in accordance with the current standards.
Weighted effective acceleration a
hv,eq
(DIN ISO 22867) m/s
2
Handle r.h. side / handle l.h. side
7,95 / 5,74
Sound pressure level L
Peq
dB(A)
(EN ISO 22868)
91,29
Sound power level L
Weq
dB(A)
(EN ISO 22868))
101,96
