Solplanet LT Series - Scope of Delivery

1
12 13 14
2
3
5
6 7
4
9
8
10
11
OVERVIEW
4
SCOPE OF DELIVERY
5
Inverterx1
1 DC connector inputs 1-6 （connected to DC switch 1）
2 DC switch 1
5 WiFi stick port
13 RS485 Communication port
14 Reserved grounding - knockout seal
6 Reserved terminal
3 DC connector inputs 13-16
（connected to DC switch 3）
4 DC switch 3
7 AC cable - knockout seal
9 DC connector inputs 7-12
（Connected to DC switch 2）
10 DC switch 2
8 Lock valve
11 DC connector inputs 17-20
（Connected to DC switch 4）
12 DC switch 4
Mounting-bracket×1
WiFi stick×1
M4×9 Screws×6
M5×12 Screws×2
M10×20 Bolt×2
RS 485 COM plug×1
DC connector (pair)×16/20
Document packagex1
Handle×4
(Optional)
Lifting ring×2
（Optional）
Expansion bolt×4
