APT250/APT500/APT1000 Operation Manual
14
True Soltec Co., Ltd.
9. I/O
The following table is the pins assignment of the I/O connector.
Pin No.
Description
In/Out
Signal
1
ZERO reset
In
One shot pulse
2
START
In
One shot pulse
3
ENT
In
One shot pulse
4
STOP
In
Level
5
GROUND
6
In measurement
Out
Contact signal, level
7
Home
Out
Contact signal, level
8
Overload
Out
Contact signal, level
9
Non use
10
Analog +
Out
Sensor signal in voltage 0 5V
11
Analog -
Out
12
Non use
13
COM
14
Non use
15
Non use
