APT250/APT500/APT1000 Operation Manual
3
True Soltec Co., Ltd.
Pull-speed adjustable-range table
Model
Volume location
（MIN）
Volume location
（MAX）
APT1000-200M
100
200
APT1000-100M
50
100
APT1000-50M
25
50
APT500-200M
100
200
APT500-100M
50
100
APT500-50M
25
50
APT250-200M
100
200
APT250-100M
50
100
APT250-50M
25
50
Pull speed adjust volume
There is a slit on the volume.
When changing speed, please adjust the
position of the slit using a flathead screwdriver.
The position of red point shows the speed which
adapted. The speed of each scale is different
from the model.
The rate of accuracy will be 10% ± for the
specified speed.
Caution at power ON
This unit is automatically adjusted to zero value when it is powered ON. Therefore,
check and confirm that no load is applied to the connector clamper.
Unit mm/min
100
200
175
125
150
ex) the speed of APT1000-200
