SOLTEK SL–54U5 - USB: USB Connector

16
USB: USB Connector
This jumper connects to the USB cable to provide USB
device.
1
USB
MS1
COM1/2
GND
D1–
D1
+
Vcc
GND
Vcc
D0
+
D0–
GND
16 15
21
GND
TX
DTR
RX
RING
RTS
CD
N.C.
CTS
DSR
12345
678910
GND
N.C.
Mouse
Data
+5v
Mouse
Clock
N.C.
MS1 Top View COM1/2 (Top View)
