SOLTEK SL–54U5 - J2 Switch Signal Summary

18
J2 Switch Signal Summary
J2 Pin Signal Description
1 Speaker Signal
Speaker Connector 2 No Connection
3 Ground
4 +5V
Reset Switch 5 Reset Signal
6 Ground
N.C. 7 No Connection
8 +5V
Power LED Connector 9 No Connection
10 Ground
Keylock Connector 11 Keylock Signal
12 GND
N.C. 13 No Connection
Turbo LED Connector 14 Turbo LED Connector
15 Ground
