SOLTEK SL–54U5 - Integrated Peripherals

34
Integrated Peripherals
Integrated Peripherals option changes the values of the
chipset registers. These registers control system options in
the computer.
1. Choose ÒINTEGRATED PERIPHERALSÓ from the Main
Menu and a screen with a list of options appears.
On-Chip IDE First Channel : Enabled
On-Chip IDE Second Channel : Enabled
IDE Prefetch Mode : Enabled
IDE HDD Block Mode : Enabled
IDE Primary Master PIO : Auto
IDE Primary Slave PIO : Auto
IDE Secondary Master PIO : Auto
IDE Secondary Slave PIO : Auto
IDE Primary Master UDMA : Auto
IDE Primary Slave UDMA : Auto
IDE Secondary Master UDMA : Auto
IDE Secondary Slave UDMA : Auto
Init Display First : PCI Slot
Onboard FDD Controller : Enabled
Onboard UART 1 : Auto
Onboard UART 2 : Auto
UART2 Mode : Standard
IR Function Duplex* : Half
RxD, TxD Active* : Lo, Lo
ROM PCI/ISA BIOS
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
ESC : Quit ↑ ↓ → ←: Select Item
F1 : Help PU/PD/+/– : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
Onboard Parallel Port : 378/IRQ7
Parallel Port Mode : SPP
ECP Mode Use DMA
+
: 3
Parallel Port EPP Type
+
: EPP1.7
*: These Settings are only effective under ÒOnboard UART 2 ModeÓ option is set HPSIR or ASKIR.
+
: These options only valid at Parallel Port Mode at ECP+EPP.
2. Use one of the arrow keys to move between options and
modify the selected options by using PgUp/PgDn/+/Ð
keys.
A short description of screen options follows:
OnChip IDE
First/Second
Channel
Enabled (default): Turn on the
onboard IDE function.
Disabled: Turn off the onboard IDE
function.
IDE Prefetch Mode Use the default setting.
