SOLTEK SL–54U5 - Default Chapter; Table of Contents

iv
Contents
Chapter 1: Introduction --------------------------------------- 1
Features ------------------------------------------------------------------------- 1
CPU ------------------------------------------------------------------------ 1
Chipset -------------------------------------------------------------------- 1
L2 Cache ------------------------------------------------------------------ 1
Main Memory ----------------------------------------------------------- 1
BIOS ------------------------------------------------------------------------ 2
I/O Function ------------------------------------------------------------- 2
Other Functions --------------------------------------------------------- 2
Mainboard Setting for Pentium MMX-200----------------------------- 3
Chapter 2: Hardware Setup---------------------------------- 4
CPU VCORE Voltage Setting---------------------------------------------- 4
JP3: CPU VCore Voltage Setting ----------------------------------- 4
AGP Driver for Win95 Installation -------------------------------------- 5
Requirement ------------------------------------------------------------- 5
Installation Procedure ------------------------------------------------- 5
Intel Pentium MMXÐ166/200/233 CPUs ------------------------------ 6
AMD K6 CPU Settings------------------------------------------------------ 7
AMD K6 Ð 166/200/233/266/300 and K6-2 266 CPUs ------- 7
AMD K6-2 Ð 250/300/333/350/380/400 CPU Settings ------------ 8
Cyrix/IBM 6x86MX Ð PR200/233/266 CPUs ------------------------- 9
IDT C6 Ð 200/225 CPUs -------------------------------------------------- 10
Intel Pentium/AMD K5 Ð 133/166/200 CPUs---------------------- 10
System Memory Configuration----------------------------------------- 11
Jumper Settings ------------------------------------------------------------- 11
JP2: Clear CMOS Data ---------------------------------------------- 11
JP17, JP18: CPU Dual/Single Voltage Select ------------------ 12
SW1: 4~6: Bus Ratio Select----------------------------------------- 12
JP1, JP6: SDRAM Clock Setting----------------------------------- 13
