The mounting bracket included with your camera provides convenient mounting to vertical
surfaces, such as walls. The camera support platform can be tilted up or down to help point
the camera toward your area of interest. You can also rotate the camera in any direction on
the platform.
Step 1. Find a suitable location to mount the camera.
Step 2. Using the mounting bracket as a guide, mark the location of the two mounting
holes.
Step 3. Drill a ¼” hole for each screw.
Step 4. Use a hammer to tap the two plastic anchors into the holes.
Step 5. Use the two screws to fasten the bracket to the wall.
Step 6. Place the camera on the mounting bracket platform and rotate the camera to be
facing in the desired direction.
Step 7. Secure the camera to the mounting bracket using the thumbscrew located on the
bottom of the platform.
Step 8. Loosen the tilt adjust thumbscrew and tilt the camera toward the area to be
observed.
CAUTION: The IP Camera should be mounted indoors or inside a
weatherproof enclosure. Outdoor exposure may result in damage and
will void your warranty.
CAUTION: Don’t mount the IP Camera with the lens facing into direct
sunlight. Prolonged exposure to direct sunlight will damage the sensor.
