I N S T R U C T I O N M A N U A L • M O D E L H 5 2 0 / H 5 4 0
15
OPTIONS
The following options and accessories are available for the H520 and H540
systems.
1. FOOT SWITCH for remote activation. (When foot switch actuation is
used, the trigger handle is removed from the hand gun housing.)
2. MANUAL ARBOR PRESS, available with foot switch or cam actuation,
is designed for assembling parts where production volume does not justify
automated equipment. The press provides a more controlled motion of the
welder than is possible by just holding the hand gun, resulting in more
consistent assemblies.
MANUAL PRESS
Always turn off the
power supply before
installing or removing
the foot switch cable.
