Sonics H520 - Installation and Set Up; Electrical Power Requirements; Setting Up; Electrical Connections

• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
8 I N S T R U C T I O N M A N U A L • M O D E L H 5 2 0 / H 5 4 0
G L O S S A R Y O F U L T R A S O N I C T E R M S
POWER SUPPLY/GENERATOR – The solid state power supply converts
standard 50/60 Hz electrical power to 20,000 Hz or 40,000 Hz (20/40 kHz)
electrical energy.
CONVERTER – The converter changes the high frequency electrical energy
supplied by the power supply to high frequency mechanical vibrations.
TIP/HORN – The tip/horn is a tuned component of the system which comes
in contact with the parts to be assembled. The tip/horn 1) transfers the
ultrasonic vibrations produced from the converter to the parts being welded,
and 2) applies necessary force to the assembly while the material resolidifies.
AMPLITUDE – The peak to peak excursion of a horn at its output face.
