Sonim XP3340 SENTINEL User Manual

23
Getting Started
Keypad key Operations
MENU KEY (CENTRE)
Present at the centre of the navigation keys.
•  Press while in standby mode to enter the main menu.
•  Press when required to be used as a toggle key to select or clear a checkbox.
•  Press to perform similar tasks as the Left Selection Key.
•  Press to select the OK command.
NAVIGATION KEYS
The Left and Right Selection Keys and Power On/Off keys surround this key group.
There are arrows on the key that denote the direction to scroll for information
displayed on the screen.
UP/DOWN
Press to move the cursor up or down in the text editor.
•  Press to view the pages in the text editor.
•  Press to browse menus/lists at the same level.
•  Press to view the previous or next picture when previewing pictures.
•  Press to browse the main menu.
LEFT/RIGHT
Press to navigate between tabs.
•  Press to move the cursor left or right in the text editor.
•  Press to browse the main menu.
ALPHA-NUMERIC KEYS
•  Press the required keys to enter the desired phone number and press to
make a call. Alternatively, enter the number and select Option > Call to dial
the number.
•  Press and hold any numeric key to access the shortcut assigned, while in
standby mode.
•  Enter text while in the text editor.
•  Press and hold in standby mode to access your Voice mail.
•  When entering text, press to enter space.

Sonim XP3340 SENTINEL Specifications

Operating Environment

operational temperature range	-20˚C to +55˚C
vibration protection	5Hz to 500Hz
shock resistance	up to 4G

Display

display size	2 inch
display resolution	240x320
display brightness	280cd/m²

Battery

battery capacity	1750 mAh
talk time	20 to 24 hours
standby time	over 800 hours

Camera

camera resolution	2 MP
camera features	LED Flash
torch light	LED

Ports & Interfaces

headset port	3.5mm waterproof
USB data port	proprietary cable
Bluetooth version	2.1

Weight and Dimensions

size	126mm x 60mm x 25mm
weight	185 grams
impact resistance	2 meter drop onto concrete
