SN8P2511
8-Bit Micro-Controller
SONiX TECHNOLOGY CO., LTD Page 6 Version 1.2
1
1
1
PRODUCT OVERVIEW
1.1 FEATURES
Features Selection Table
Migration SN8P2501B to SN8P2511
In RTC mode, clear T0IRQ must be after
1/2 RTC clock source (32768Hz), or the
RTC interval time is error.
IHRC_16M and IHRC_RTC modes don't
support Fosc/1 and Fosc/2.
SN8P2511 is compatible to SN8P2501B.
SN8P2501B code can transfer to SN8P2511 directly. Program the original SN8 of SN8P2501B into SN8P2511
directly with declare SN8P2511 chip name in source code and re-compile again.
Fcpu = Fosc/1, Fosc/2, Fosc/4, Fosc/8, Fosc/16.
One 8-bit basic timer with RTC (0.5Sec).
One 8-bit timer with external event counter,
2 internal interrupts: T0, TC0
On chip watchdog timer and clock source is
1 external interrupt: INT0
Internal low clock RC type (16KHz(3V), 32KHz(5V))
Bi-directional: P0, P1, P2, P5.
External high clock: RC type up to 10 MHz
Wakeup: P0, P1 level change.
External high clock: Crystal type up to 16 MHz
Pull-up resisters: P0, P1, P2, P5.
Internal high clock: 16MHz RC type
Internal low clock: RC type 16KHz(3V), 32KHz(5V)
Programmable open-drain: P1.0
External interrupt: P0.0 (PEDGE edge trigger)
Normal mode: Both high and low clock active
Slow mode: Low clock only.
Reset system and power monitor.
Sleep mode: Both high and low clock stop
Green mode: Periodical wakeup by T0 timer
Instruction’s length is one word.
Package (Chip form support)
Most of instructions are one cycle only.
All ROM area JMP/CALL instruction.
All ROM area lookup table function (MOVC).
