ELECTRICAL CHARACTERISTIC
10.1 ABSOLUTE MAXIMUM RATING
Supply voltage (Vdd)…………………………………………………………………………………………………………………….……………… - 0.3V ~ 6.0V
Input in voltage (Vin)…………………………………………………………………………………………………………………….… Vss – 0.2V ~ Vdd + 0.2V
Operating ambient temperature (Topr)
SN8P2511P, SN8P2511S, SN8P2511X ……………………………………..……………………...………..………………………..........0C ~ + 70C
Storage ambient temperature (Tstor) ………………………………………………………………….………………………………………… –40C ~ + 125C
10.2 ELECTRICAL CHARACTERISTIC
 DC CHARACTERISTIC
(All of voltages refer to Vss, Vdd = 5.0V, Fosc = 4MHz, Fcpu=1MHz, ambient temperature is 25  C unless otherwise note.)
PARAMETER
SYM.
DESCRIPTION
MIN.
TYP.
MAX.
UNIT
Operating voltage
Vdd
Normal mode, Vpp = Vdd, -40  C ~85  C,
Fcpu = 1MHz
2.2
-
5.5
V
RAM Data Retention voltage
Vdr
1.5
-
-
V
*Vdd rise rate
Vpor
Vdd rise rate to ensure internal power-on reset
0.05
-
-
V/ms
Input Low Voltage
ViL1
All input ports
Vss
-
0.3Vdd
V
ViL2
Reset pin
Vss
-
0.2Vdd
V
Input High Voltage
ViH1
All input ports
0.7Vdd
-
Vdd
V
ViH2
Reset pin
0.8Vdd
-
Vdd
V
Reset pin leakage current
Ilekg
Vin = Vdd, 25  C
-
-
2
uA
I/O port input leakage current
Ilekg
Pull-up resistor disable, Vin = Vdd
-
-
2
uA
I/O port pull-up resistor
Rup
Vin = Vss , Vdd = 3V
100
200
300
K
Vin = Vss , Vdd = 5V
50
100
180
I/O output source current
IoH
Vop = Vdd – 0.5V
8
15
-
mA
sink current
IoL
Vop = Vss + 0.5V
8
15
-
*INTn trigger pulse width
Tint0
INT0 interrupt request pulse width
2/fcpu
-
-
cycle
Supply Current
Idd1
Run Mode
(No loading,
Fcpu = Fosc/4)
Vdd= 5V, 4Mhz
-
3
5
mA
Vdd= 3V, 4Mhz
-
1.5
2
mA
Idd2
Slow Mode
(Internal low RC,
Stop high clock)
Vdd=5V, ILRC 32Khz
-
20
40
uA
Vdd=3V, ILRC 16Khz
-
5
10
uA
Idd3
Sleep Mode
Vdd= 5V, 25  C
-
0.8
1.6
uA
Vdd= 3V, 25  C
-
0.7
1.4
uA
Idd4
Green Mode
(No loading,
Fcpu = Fosc/4,
Watchdog Disable)
Vdd= 5V, 4Mhz
-
0.6
1.2
mA
Vdd= 3V, 4Mhz
-
0.25
0.5
mA
Vdd=5V, ILRC 32Khz
-
15
30
uA
Vdd=3V, ILRC 16Khz
-
3
6
uA
Internal High Oscillator Freq.
Fihrc
Internal Hihg RC
(IHRC)
25  C,
Vdd= 5V,Fcpu = 1MHz
15.68
16
16.32
Mhz
LVD Voltage
Vdet0
Low voltage reset level, 0C ~ + 70C
1.6
2.0
2.2
V
Vdet1
Low voltage reset/indicator level. Fcpu = 1 MHz,
0C ~ + 70C
1.8
2.4
3
V
Vdet2
Low voltage reset/indicator level. Fcpu = 1 MHz,
0C ~ + 70C
2.5
3.6
4.5
V
External oscillator (32KHz)
match capacitor
C
32K
Capacitor selection for crystal oscillator in 32KHz
20
27
33
pF
“
*
” These parameters are for design reference, not tested.
