SONIX SN8P2511 - SOP 14 PIN

SN8P2511
8-Bit Micro-Controller
SONiX TECHNOLOGY CO., LTD Page 91 Version 1.2
14.2 SOP 14 PIN
SYMBOLS
MIN
NOR
MAX
MIN
NOR
MAX
(inch)
(mm)
A
0.058
0.064
0.068
1.4732
1.6256
1.7272
A1
0.004
-
0.010
0.1016
-
0.254
B
0.013
0.016
0.020
0.3302
0.4064
0.508
C
0.0075
0.008
0.0098
0.1905
0.2032
0.2490
D
0.336
0.341
0.344
8.5344
8.6614
8.7376
E
0.150
0.154
0.157
3.81
3.9116
3.9878
e
-
0.050
-
-
1.27
-
H
0.228
0.236
0.244
5.7912
5.9944
6.1976
L
0.015
0.025
0.050
0.381
0.635
1.27
θ°
0°
-
8°
0°
-
8°
