SONOFF TECHNOLOGIES CO., LTD.
English
>
3. Add sub-devices
Connect the Bridge before adding the sub-device
Access eWeLink APP, select the Bridge that you want to connect,
and tap “Add” to add a sub-device. Then long press reset button on
the device for 5s until the LED indicator flashes three times, which
means the device has entered the pairing mode, and be patient
until pairing completes.
ZBB ridge
Add ed:0
No c hild d evice ,plea se add .
Add
If the addition failed, move the sub-device closer to the Bridge and try again.
Specifications
Model
Battery model
Wireless connection
Working temperature
Working humidity
Material
Dimension
SNZB-03
CR2450(3V)
ZigBee (IEEE 802.15.4)
-10℃~40℃
10-90%RH (non-condensing)
PC
40x35x28mm

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sonoff SNZB-03 and is the answer not in the manual?

Sonoff SNZB-03 Specifications

General IconGeneral
TypeMotion Sensor
Battery TypeCR2450
Detection Angle110°
Operating Temperature-10°C to 40°C
Operating Voltage3V
Wireless ProtocolZigbee
Detection Range5 meters
Dimensions35x39x28mm
Operating Humidity10% to 90% RH
Battery Life2 Years
CompatibilityCompatible with Zigbee 3.0 hubs
