Sonos Beam User Manual

SONOS USER GUIDE
1. Remove the protective cap from the optical adapter.
2. Attach the optical adapter to the HDMI cable.
3. Connect the optical adapter to the TV’s optical digital OUT port.
Note: The optical adapter’s port is “D-shaped”—make sure the connector aligns correctly into the port.
Inserting the adapter incorrectly may damage the cable.
If you don’t have the app, download it from the app store. You’ll use it to set up and control your Sonos
system. See Getting started
.
Microphone on/off
Touch to turn the microphone on and off. (If you don’t have a voice service installed, the microphone is
inactive.)
Optical adapter
HDMI cable
Remove the protective cap
TV’s optical digital OUT port
Beam’s HDMI port
Optical adapter attached to HDMI cable

Sonos Beam Specifications

General

Disc types supported	-
Optical disc player type	Not included
RMS rated power	- W
Audio output channels	4.0 channels
Audio Return Channel (ARC)	Yes
Product color	Black
Built-in display	No
Virtual assistant	Amazon Alexa & Google Assistant
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless

Weight and Dimensions

Depth	100 mm
Width	651 mm
Height	68.5 mm
Soundbar weight	2800 g
