6 Acquiring Images
74 Basic User Manual
■ Sector Width/Angle
Sector width (for linear probes) or sector angle (for curved and phased array probes) is used to adjust the frame
rate. You can adjust the sector width or angle to get more information without moving the probe.
The region of interest of the object can be adjusted after you adjust the sector width or sector angle.
To adjust the sector width/angle:
Tap the left or right part of
Sec. Width
on the touch screen to change the sector width or angle.
■ Sector Position
Sector position is used to move or rotate the image.
To adjust the sector position:
Tap the left or right part of
Sector Pos
on the touch screen to move or rotate the image.
■ Power
Power is used to select the amount of ultrasound acoustic power produced by the probe. The adjustment range of
the power is 0-100%, and ±10% can be adjusted each time. The real time value of the power is displayed in the
imaging information area of the basic screen.
To adjust the power:
●
Tap the left part of
Power%
on the touch screen to decrease the value.
●
Tap the right part of
Power%
on the touch screen to increase the value.
NOTE:
Expose the patient to the lowest practical transmit power level for the shortest possible time to achieve a
satisfactory diagnosis.
■ B Reject
B Reject is used to set the display priorities of the color and 2D grayscale pixels. A larger B Reject value suppresses
more grayscale pixels.
To adjust B Reject:
●
Tap the left part of
B Reject
on the touch screen to decrease the value.
●
Tap the right part of
B Reject
on the touch screen to increase the value.
■ Steer
Steer is used to adjust the angle of CF ROI when performing a real time scan by using the linear probes.
To adjust the steer:
●
Tap the left part of
Steer
on the touch screen to rotate the angle clockwise.
●
Tap the right part of
Steer
on the touch screen to rotate the angle anticlockwise.
NOTE:
Only the linear probes are available when adjusting steer.
■ Flow Invert
Flow invert is used to view blood ow from a different perspective.
When
Invert
is set to
OFF
, red pixels represent flow to the probe; blue pixels represent flow away from the
probe.
When
Invert i
s set to
ON
, blue pixels represent ow to the probe; red pixels represent ow away from the probe.
To enable or disable the ow invert:
