Preparations for shooting
Top side/Side view
Drive mode dial lock release
button
Upper: Drive mode dial
Lower: Focus mode dial (40)
Focus mode dial lock release
button
LAN terminal
(Flash sync) terminal
Speaker
(Microphone) jack
When an external microphone
is connected, the built-
in microphone turns off
automatically. When the
external microphone is a
plugin-power type, the power
of the microphone is supplied
by the camera.
(Headphones) jack
HDMI micro jack
Charge lamp
Multi/Micro USB Terminal*
(66)
This terminal supports Micro
USB-compatible devices.
To Next Page
