A
E22 RDQ12 I/O
Memory data bit 12
A
H22 RDQ13 I/O
Memory data bit 13
A
D22 RDQ14 I/O
Memory data bit 14
A
F21 RDQ15 I/O
Memory data bit 15
A
G7 RDQ16 I/O
Memory data bit 16
A
H7 RDQ17 I/O
Memory data bit 17
A
H8 RDQ18 I/O
Memory data bit 18
A
G8 RDQ19 I/O
Memory data bit 19
A
F12 RDQ20 I/O
Memory data bit 20
A
E12 RDQ21 I/O
Memory data bit 21
A
C12 RDQ22 I/O
Memory data bit 22
A
D12 RDQ23 I/O
Memory data bit 23
A
E8 RDQ24 I/O
Memory data bit 24
A
F8 RDQ25 I/O
Memory data bit 25
A
E9 RDQ26 I/O
Memory data bit 26
A
F9 RDQ27 I/O
Memory data bit 27
A
H11 RDQ28 I/O
Memory data bit 28
A
G11 RDQ29 I/O
Memory data bit 29
A
F11 RDQ30 I/O
Memory data bit 30
A
E11 RDQ31 I/O
Memory data bit 31
A
E21 RDQM0 O
Memory data mask bit 0
A
D21 RDQM1 O
Memory data mask bit 1
A
D10 RDQM2 O
Memory data mask bit 2
A
D9 RDQM3 O
Memory data mask bit 3
A
G20 RDQS0 I/O
Memory positive data strobe bit 0
A
H20 RDQS0
_
I/O
Memory negative data strobe bit 0
A
H21 RDQS1 I/O
Memory positive data strobe bit 1
A
G21 RDQS1
_
I/O
Memory negative data strobe bit 1
A
G9 RDQS2 I/O
Memory positive data strobe bit 2
A
H9 RDQS2
_
I/O
Memory negative data strobe bit 2
A
H10 RDQS3 I/O
Memory positive data strobe bit 3
A
G10 RDQS3
_
I/O
Memory negative data strobe bit 3
A
C14 RODT O
Memory on die termination enable
A
C13 RRAS
_
O
Memory row address strobe
A
B12 RVREF
_
1I
Memory VREF
A
A20 RVREF
_
2I
Memory VREF
A
E13 RWE
_
O
Memory write enable
A
C16 RRESET O
Memory reset
A
E27 RA0
_
BO
Memory address bit 0
U24 RA1
_
B O
Memory address bit 1
W28 RA2
_
B O
Memory address bit 2
A
A27 RA3
_
B O
Memory address bit 3
V24 RA4
_
BO
Memory address bit 4
A
A28 RA5
_
B O
Memory address bit 5
W24 RA6
_
B O
Memory address bit 6
W27 RA7
_
BO
Memory address bit 7
Y24 RA8
_
BO
Memory address bit 8
W26 RA9
_
B O
Memory address bit 9
V28 RA10
_
B O
Memory address bit 10
V23 RA11
_
BO
Memory address bit 11
U23 RA12
_
BO
Memory address bit 12
Y25 RA13
_
BO
Memory address bit 13
A
B26 RBA0
_
BO
Memory bank address bit 0
T24 RBA1
_
B O
Memory bank address bit 1
W25 RBA2
_
B O
Memory bank address bit 2
A
C26 RCAS
__
BO
Memory column address strobe
V27 RCKE
_
B O
Memory clock enable
L27 RCLK0
_
BO
Memory clock 0 positive
L28 RCLK0
__
B O
Memory clock 0 negative
A
B27 RCLK1
_
BO
Memory clock 1 positive
A
B28 RCLK1
__
BO
Memory clock 1 negative
A
B25 RCS
__
BO
Memory chip select
T25 RDQ0
_
B I/O
Memory data bit 0
T26 RDQ1
_
B I/O
Memory data bit 1
U26 RDQ2
_
B I/O
Memory data bit 2
U25 RDQ3
_
B I/O
Memory data bit 3
M26 RDQ4
_
B I/O
Memory data bit 4
M25 RDQ5
_
B I/O
Memory data bit 5
N28 RDQ6
_
B I/O
Memory data bit 6
N27 RDQ7
_
B I/O
Memory data bit 7
P23 RDQ8
_
B I/O
Memory data bit 8
T28 RDQ9
_
B I/O
Memory data bit 9
T27 RDQ10
_
B I/O
Memory data bit 10
T23 RDQ11
_
B I/O
Memory data bit 11
N26 RDQ12
_
B I/O
Memory data bit 12
P24 RDQ13
_
B I/O
Memory data bit 13
N23 RDQ14
_
B I/O
Memory data bit 14
N24 RDQ15
_
B I/O
Memory data bit 15
A
F25 RDQ16
_
B I/O
Memory data bit 16
A
G25 RDQ17
_
B I/O
Memory data bit 17
A
H25 RDQ18
_
B I/O
Memory data bit 18
A
H26 RDQ19
_
B I/O
Memory data bit 19
A
A24 RDQ20
_
B I/O
Memory data bit 20
A
B24 RDQ21
_
B I/O
Memory data bit 21
A
A23 RDQ22
_
B I/O
Memory data bit 22
A
B23 RDQ23
_
B I/O
Memory data bit 23
BDP-S485
6-4
