Sony BKM-142HD - 6 Block Diagrams; Bx (Bkm-129 X); Bx (2;2) Bkm-129 X

5-15
BKM-120D/127W/129X/142HD
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
* A-1136-013-A BX COMPL (BKM-129X)
***********
<CAPACITOR>
C010 1-128-526-11 ELECT 100µF 20% 16V
C011 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C012 1-128-526-11 ELECT 100µF 20% 16V
C013 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C014 1-128-526-11 ELECT 100µF 20% 16V
C015 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C016 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C017 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C018 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C019 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C020 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C021 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C022 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C050 1-128-526-11 ELECT 100µF 20% 16V
C051 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C052 1-128-526-11 ELECT 100µF 20% 16V
C053 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C054 1-128-526-11 ELECT 100µF 20% 16V
C055 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C056 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C057 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C058 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C059 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C060 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C061 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C062 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C101 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C102 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C103 1-107-701-11 ELECT 47µF 20% 16V
C104 1-107-725-11 CERAMIC CHIP 0.1µF 10% 16V
C106 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C201 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C202 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C203 1-107-701-11 ELECT 47µF 20% 16V
C204 1-107-725-11 CERAMIC CHIP 0.1µF 10% 16V
C206 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C301 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C302 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C303 1-107-701-11 ELECT 47µF 20% 16V
C304 1-107-725-11 CERAMIC CHIP 0.1µF 10% 16V
C306 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C401 1-163-091-00 CERAMIC CHIP 8PF 0.25PF 50V
C402 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C403 1-107-701-11 ELECT 47µF 20% 16V
C404 1-107-725-11 CERAMIC CHIP 0.1µF 10% 16V
C501 1-128-526-11 ELECT 100µF 20% 16V
C502 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C503 1-163-038-91 CERAMIC CHIP 0.1µF 25V
<CONNECTOR>
CN001 * 1-774-523-11 PIN, CONNECTOR (PC BOARD) 64P
<DIODE>
D101 8-719-073-01 DIODE MA111-(K8).S0
D102 8-719-073-01 DIODE MA111-(K8).S0
D201 8-719-073-01 DIODE MA111-(K8).S0
D202 8-719-073-01 DIODE MA111-(K8).S0
D301 8-719-073-01 DIODE MA111-(K8).S0
D302 8-719-073-01 DIODE MA111-(K8).S0
D401 8-719-073-01 DIODE MA111-(K8).S0
D402 8-719-073-01 DIODE MA111-(K8).S0
D501 8-719-158-19 DIODE RD6.2SB
<FILTER>
FL501 1-239-183-11 FILTER, EMI
FL502 1-239-480-11 FILTER, EMI
FL503 1-239-480-11 FILTER, EMI
<IC>
IC010 8-759-460-74 IC BA05FP-E2
IC050 8-759-539-89 IC LM2990SX-5.0
IC501 8-759-594-41 IC MB89613R-651
IC502 8-759-186-44 IC TC74VHC125F
IC503 8-759-156-54 IC X25040SI
<TRANSISTOR>
Q101 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q102 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q103 8-729-107-31 TRANSISTOR 2SC3545-T43
Q201 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q202 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q203 8-729-107-31 TRANSISTOR 2SC3545-T43
Q301 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q302 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q303 8-729-107-31 TRANSISTOR 2SC3545-T43
Q401 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q402 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q403 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q404 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q501 1-801-806-11 TRANSISTOR DTC144EKA-T146
<RESISTOR>
R101 1-214-837-11 METAL 75 1% 1/2W
R102 1-216-089-91 RES,CHIP 47K 5% 1/10W
R103 1-216-025-91 RES,CHIP 100 5% 1/10W
R104 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R105 1-216-097-91 RES,CHIP 100K 5% 1/10W
R106 1-216-009-91 RES,CHIP 22 5% 1/10W
R107 1-216-025-91 RES,CHIP 100 5% 1/10W
R108 1-216-097-91 RES,CHIP 100K 5% 1/10W
R109 1-216-013-00 RES,CHIP 33 5% 1/10W
R201 1-214-837-11 METAL 75 1% 1/2W
R202 1-216-089-91 RES,CHIP 47K 5% 1/10W
R203 1-216-025-91 RES,CHIP 100 5% 1/10W
R204 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R205 1-216-097-91 RES,CHIP 100K 5% 1/10W
R206 1-216-009-91 RES,CHIP 22 5% 1/10W
R207 1-216-025-91 RES,CHIP 100 5% 1/10W
R208 1-216-097-91 RES,CHIP 100K 5% 1/10W
R209 1-216-013-00 RES,CHIP 33 5% 1/10W
R301 1-214-837-11 METAL 75 1% 1/2W
R302 1-216-089-91 RES,CHIP 47K 5% 1/10W
R303 1-216-025-91 RES,CHIP 100 5% 1/10W
R304 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R305 1-216-097-91 RES,CHIP 100K 5% 1/10W
R306 1-216-009-91 RES,CHIP 22 5% 1/10W
R307 1-216-025-91 RES,CHIP 100 5% 1/10W
R308 1-216-097-91 RES,CHIP 100K 5% 1/10W
R309 1-216-013-00 RES,CHIP 33 5% 1/10W
R401 1-214-837-11 METAL 75 1% 1/2W
R402 1-216-089-91 RES,CHIP 47K 5% 1/10W
R403 1-216-049-91 RES,CHIP 1K 5% 1/10W
BX
BKM-129X
