Sony CCP-8000 - System Description

1-2
MVS-8000 System
SYSTEM SETUP
1-3. System Description
The MVS-8000 System consists of Switcher Processor Pack (MVS-8400/8300/8200), DME Processor
Pack (MVE-8000), Center Control Panel Pack (CCP-8000) and Device Control Unit Pack (DCU-8000).
1-3. System Description
MVE-8000
DCU-8000
MVS-8400/8300/8200
AUX PANEL
MENU PANEL
MIAN PANEL
POWER A
SYSTEM CONTROL UNIT MKS-8010
MKS-8010
CCP-8000
