– 63 –
MAIN BOARD IC201 CXD8607N (A/D, D/A CONVERTER)
Pin No. Pin Name I/O Function
1 INRP I R-ch analog signal (+) input terminal
2 INRM I R-ch analog signal (–) input terminal
3 REFI I Reference voltage (+3.3V) input terminal (for A/D converter section)
4 AVDD — Power supply terminal (+5V) (for A/D converter section, analog system)
5 AVSS — Ground terminal (for A/D converter section, analog system)
6 APD I Power down detection input of the A/D converter section (for analog section) “L”: power down
7 NU — Not used (open)
8 NU — Not used (open)
9 TEST1 I Input terminal for the test (fixed at “L”)
10 LRCK1 I
L/R sampling clock signal (44.1 kHz) input from the CXD2650R (IC121) (for A/D converter
section)
11 BCK1 I Bit clock signal (2.8224 MHz) input from the CXD2650R (IC121) (for A/D converter section)
12 ADDT O Recording data output terminal
13 V35A — Power supply terminal (+3.3V) (for analog system)
14 VSS1 — Ground terminal (for A/D converter section, digital system)
15 MCKI I Master clock (256Fs=11.2896 MHz) input of the A/D converter section
16 DPD I
Reset signal input from the system controller (IC401) Reset signal is used as a detection signal o
f
power down to A/D converter section (digital section) “L”: reset (power down)
17 VSS2 — Ground terminal (for D/A converter section, digital system)
18 RES I
Reset signal input from the system controller (IC401)
Reset signal is used as a initialize signal to D/A converter section “L”: reset (initialize)
19 MODE I Writing data input from the system controller (IC401)
20 SHIFT I Serial clock signal input from the system controller (IC401)
21 XLATCH I Serial latch signal input from the system controller (IC401)
22 256CK O 256Fs (11.2896 MHz) clock signal output terminal
23 V35D — Power supply terminal (+3.3V) (for digital system)
24 VSS2 — Ground terminal (for D/A converter section, digital system)
25 512FS O 512Fs (22.5792 MHz) clock signal output to the CXD2650R (IC121)
26 BCK2 I Bit clock signal (2.8224 MHz) input from the CXD2650R (IC121) (for D/A converter section)
27 DADT I Playback data input terminal
28 LRCK2 I
L/R sampling clock signal (44.1 kHz) input from the CXD2650R (IC121) (for D/A converter
section)
29 VDD2 — Power supply terminal (+5V) (for D/A converter section, digital system)
30 R1 O R-ch PLM signal 1 output terminal
31 AVDDR — Power supply terminal (+5V) (for R-ch side D/A converter section, analog system)
32 R2 O R-ch PLM signal 2 output terminal
33 AVSSR — Ground terminal (for R-ch side D/A converter section, analog system)
34 XVDD — Power supply terminal (+5V) (for X’tal system)
35 XOUT O System clock output terminal (22 MHz)
36 XIN I System clock input terminal (22 MHz)
37 XVSS — Ground terminal (for X’tal system)
38 AVSSL — Ground terminal (for L-ch side D/A converter section, analog system)
39 L2 O L-ch PLM signal 2 output terminal
40 AVDDL — Power supply terminal (+5V) (for L-ch side D/A converter section, analog system)
41 L1 O L-ch PLM signal 1 output terminal
42 VDD2 — Power supply terminal (+5V) (for L-ch side D/A converter section, digital system)
