Sony CDP-EX770 - Electrical Parts List

– 71 –
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
SECTION 8
ELECTRICAL PARTS LIST
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
BD
When indicating parts by reference
number, please include the board.
* A-4699-092-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C102 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C103 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C104 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C105 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C106 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C107 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C108 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C109 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C110 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C111 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C112 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C113 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C115 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C116 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C117 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C119 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C121 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C122 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C123 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C124 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C127 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C128 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C129 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C130 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C131 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C132 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C133 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C134 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C135 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C136 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C141 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C142 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C143 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C144 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C146 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C151 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C152 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C153 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C156 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C158 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C160 1-104-601-11 ELECT CHIP 10uF 20% 10V
C161 1-104-601-11 ELECT CHIP 10uF 20% 10V
C163 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C164 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C167 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C168 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C169 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C171 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C181 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C182 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C183 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C184 1-107-836-11 ELECT CHIP 22uF 20% 8V
C185 1-164-611-11 CERAMIC CHIP 0.001uF 10% 500V
C187 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C188 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C189 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C190 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C191 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C195 1-164-346-11 CERAMIC CHIP 1uF 16V
C196 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C197 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-766-508-11 CONNECTOR, FFC/FPC (ZIF) 22P
CN102 1-778-461-11 CONNECTOR, FFC/FPC 29P
CN103 1-778-460-11 CONNECTOR, FFC/FPC 19P
CN104 1-766-898-21 HOUSING, CONNECTOR (PC BOARD) 4P
CN106 1-770-698-11 CONNECTOR, FFC/FPC 15P
CN110 1-774-731-21 PIN, CONNECTOR (PC BOARD) 5P
< DIODE >
D101 8-719-988-62 DIODE 1SS355
D181 8-719-046-86 DIODE F1J6TP
D183 8-719-046-86 DIODE F1J6TP
< IC/TRANSISTOR >
IC101 8-752-074-77 IC CXA2523R
IC103 8-729-903-10 TRANSISTOR FMW1
IC121 8-752-378-54 IC CXD2650R
IC122 8-759-234-20 IC TC7S08F
IC123 8-759-242-70 IC TC7WU04F
IC152 8-759-430-25 IC BH6511FS-E2
