– 72 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
IC171 8-759-428-58 IC XL24C01AF-E2
IC181 8-759-095-65 IC TC74ACT540FS
IC192 8-759-426-95 IC L88MS33T-TL
< COIL/FERRITE BEAD >
L101 1-414-235-11 INDUCTOR, FERRITE BEAD
L102 1-414-235-11 INDUCTOR, FERRITE BEAD
L103 1-414-235-11 INDUCTOR, FERRITE BEAD
L105 1-414-235-11 INDUCTOR, FERRITE BEAD
L106 1-414-235-11 INDUCTOR, FERRITE BEAD
L121 1-414-235-11 INDUCTOR, FERRITE BEAD
L122 1-414-235-11 INDUCTOR, FERRITE BEAD
L151 1-412-622-51 INDUCTOR CHIP 10uH
L152 1-412-622-51 INDUCTOR CHIP 10uH
L153 1-412-039-51 INDUCTOR CHIP 100uH
L154 1-412-039-51 INDUCTOR CHIP 100uH
L161 1-414-235-11 INDUCTOR, FERRITE BEAD
L162 1-414-235-11 INDUCTOR, FERRITE BEAD
< TRANSISTOR >
Q101 8-729-403-35 TRANSISTOR UN5113
Q102 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q103 8-729-014-04 TRANSISTOR RN1307-TE85L
Q104 8-729-014-04 TRANSISTOR RN1307-TE85L
Q162 8-729-101-07 TRANSISTOR 2SB798-DL
Q163 8-729-403-35 TRANSISTOR UN5113
Q180 8-729-907-00 TRANSISTOR DTC114EU
Q181 8-729-018-75 FET 2SJ278MY
Q182 8-729-017-65 FET 2SK1764KY
< RESISTOR/CHIP CONDUCTOR >
R101 1-216-295-00 CONDUCTOR, CHIP (2012)
R103 1-216-049-00 METAL CHIP 1K 5% 1/10W
R104 1-216-073-00 METAL CHIP 10K 5% 1/10W
R105 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R106 1-216-133-00 METAL CHIP 3.3M 5% 1/10W
R107 1-216-113-00 METAL CHIP 470K 5% 1/10W
R109 1-216-295-00 CONDUCTOR, CHIP (2012)
R110 1-216-073-00 METAL CHIP 10K 5% 1/10W
R111 1-216-295-00 CONDUCTOR, CHIP (2012)
R112 1-216-089-00 METAL CHIP 47K 5% 1/10W
R113 1-216-049-00 METAL CHIP 1K 5% 1/10W
R115 1-216-049-00 METAL CHIP 1K 5% 1/10W
R117 1-216-113-00 METAL CHIP 470K 5% 1/10W
R120 1-216-025-00 METAL CHIP 100 5% 1/10W
R121 1-216-097-00 METAL CHIP 100K 5% 1/10W
R123 1-216-033-00 METAL CHIP 220 5% 1/10W
R124 1-216-025-00 METAL CHIP 100 5% 1/10W
R125 1-216-025-00 METAL CHIP 100 5% 1/10W
R127 1-216-025-00 METAL CHIP 100 5% 1/10W
R131 1-216-073-00 METAL CHIP 10K 5% 1/10W
R132 1-216-097-00 METAL CHIP 100K 5% 1/10W
R133 1-216-117-00 METAL CHIP 680K 5% 1/10W
R134 1-216-049-00 METAL CHIP 1K 5% 1/10W
R135 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R136 1-216-049-00 METAL CHIP 1K 5% 1/10W
R137 1-216-025-00 METAL CHIP 100 5% 1/10W
R140 1-216-029-00 METAL CHIP 150 5% 1/10W
R141 1-216-295-00 CONDUCTOR, CHIP (2012)
R142 1-216-073-00 METAL CHIP 10K 5% 1/10W
R143 1-216-073-00 METAL CHIP 10K 5% 1/10W
R144 1-216-025-00 METAL CHIP 100 5% 1/10W
R146 1-216-037-00 METAL CHIP 330 5% 1/10W
R147 1-216-025-00 METAL CHIP 100 5% 1/10W
R148 1-216-045-00 METAL CHIP 680 5% 1/10W
R150 1-216-295-00 CONDUCTOR, CHIP (2012)
R158 1-216-097-00 METAL CHIP 100K 5% 1/10W
R159 1-216-097-00 METAL CHIP 100K 5% 1/10W
R161 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R162 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R163 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R164 1-216-045-00 METAL CHIP 680 5% 1/10W
R165 1-216-097-00 METAL CHIP 100K 5% 1/10W
R166 1-220-149-11 METAL CHIP 2.2 10% 1/2W
R167 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R169 1-219-724-11 METAL CHIP 1 1% 1/4W
R170 1-216-073-00 METAL CHIP 10K 5% 1/10W
R171 1-216-073-00 METAL CHIP 10K 5% 1/10W
R172 1-216-295-00 CONDUCTOR, CHIP (2012)
R173 1-216-121-00 METAL CHIP 1M 5% 1/10W
R175 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R176 1-216-295-00 CONDUCTOR, CHIP (2012)
R177 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R178 1-216-295-00 CONDUCTOR, CHIP (2012)
R179 1-216-089-00 METAL CHIP 47K 5% 1/10W
R180 1-216-073-00 METAL CHIP 10K 5% 1/10W
R181 1-216-073-00 METAL CHIP 10K 5% 1/10W
R182 1-216-089-00 METAL CHIP 47K 5% 1/10W
R183 1-216-089-00 METAL CHIP 47K 5% 1/10W
R183 1-216-089-00 METAL CHIP 47K 5% 1/10W
R184 1-216-073-00 METAL CHIP 10K 5% 1/10W
R185 1-216-073-00 METAL CHIP 10K 5% 1/10W
R186 1-216-296-00 CONDUCTOR, CHIP (3216)
R187 1-216-296-00 CONDUCTOR, CHIP (3216)
R188 1-216-073-00 METAL CHIP 10K 5% 1/10W
R189 1-216-073-00 METAL CHIP 10K 5% 1/10W
R190 1-216-073-00 METAL CHIP 10K 5% 1/10W
R195 1-216-295-00 CONDUCTOR, CHIP (2012)
R196 1-216-295-00 CONDUCTOR, CHIP (2012)
R198 1-216-295-00 CONDUCTOR, CHIP (2012)
R199 1-216-295-00 CONDUCTOR, CHIP (2012)
R200 1-216-295-00 CONDUCTOR, CHIP (2012)
R201 1-216-295-00 CONDUCTOR, CHIP (2012)
R202 1-216-295-00 CONDUCTOR, CHIP (2012)
R502 1-216-295-00 CONDUCTOR, CHIP (2012)
R504 1-216-295-00 CONDUCTOR, CHIP (2012)
************************************************************
* A-4699-656-A MAIN BOARD, COMPLETE
*********************
< LITHIUM BATTERY >
BA501 1-528-739-11 BATTERY, LITHIUM (VL2020 3V)
< CAPACITOR >
C001 1-115-364-11 ELECT 22000uF 20% 16V
C002 1-126-941-11 ELECT 470uF 20% 25V
C003 1-126-968-11 ELECT 100uF 20% 50V
BD MAIN
