Sony CDP-EX770 - Disassembly

SECTION 2
DISASSEMBLY
– 7 –
Note: Follow the disassembly procedure in the numerical order given.
1 two screws
(case 3 TP2)
1 two screws
(case 3 TP2)
4 three screws
(BVTP3 × 10)
8 main board
3 flat wire (19 core)
(CN102)
7 two claws
2 case
6 claw
5 two screws
(BVTP3 × 8)
