– 11 –
IC701 µPC1237HA
1 2 3
4 5 6 7 8
OVER LOAD DET
F/F
OFFSET DET
LATCH/
AUTORESET
V
CC ON
MUTE
AC OFF
DET
V
CC
• Waveforms
1 IC101 7 (XIN)
5.5 Vp-p
4 MHz
2 IC101 8 (XOUT)
5.7 Vp-p
4 MHz
