TA-EX660/EX770
AEP Model
UK Model
SERVICE MANUAL
MICROFILM
Ref. No. Part No. Description
9-922-858-11
Sony Corporation
Home A&V Products Company
INTEGRATED STEREO AMPLIFIER
98D001648-1D
Printed in Japan ©1998.4
Published by Quality Assurance Dept.
(Shibaura)
TA-EX660/EX770 is the amplifier section in MHC-EX660 and DHC-EX770MD.
The mechanical and electorical specifications of TA-EX660/EX770 is almost same as
TA-EX66/EX77 AEP/UK model.
So this manual contains only the points which differ from TA-EX66/EX77.
For the informations not contained in this manual, please refer to the TA-EX66/EX77
service manuals (9-960-931- ) previously issued.
•PARTS LIST (The difference between TA-EX66/EX77 and TA-EX660/770)
Page
1 4-985-925-01 KNOB(JOG)
2 X-4947-837-1 KNOB(VOL)ASSY
4 X-4948-359-1 PANEL ASSY, FRONT(EX66)
4 X-4948-436-1 PANEL ASSY, FRONT(EX77:AEP, UK)
* 58 4-985-927-11 PANEL, BACK(EX77:AEP,UK)
* 58 4-985-927-41 PANEL, BACK(EX66:AEP,UK)
Ref. No. Part No. Description
––––––– ––––––– –––––––––
22
TA-EX66/EX77 TA-EX660/EX770
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
1 4-985-925-11 KNOB(JOG)
2 X-4949-863-1 KNOB(VOL)ASSY
4 X-4949-867-1 PANEL ASSY, FRONT(EX660)
4 X-4949-862-1 PANEL ASSY, FRONT(EX770)
* 58 4-985-927-61 PANEL, BACK(EX770)
* 58 4-985-927-71 PANEL, BACK(EX660)
23
