– 24 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Abbreviation
HK : Hong Kong
SP : Singapore
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-663-932-11 CONNECTOR BOARD
*****************
< CAPACITOR >
C821 1-136-153-00 FILM 0.01uF 5% 50V
C831 1-136-153-00 FILM 0.01uF 5% 50V
< CONNECTOR >
* CN531 1-569-499-11 PIN, CONNECTOR 3P
CN541 1-770-966-11 PIN, CONNECTOR (PCB) (V TYPE) 6P
CN552 1-764-325-11 PIN, CONNECTOR (PCB) (V TYPE) 2P (EX77)
* CN553 1-569-504-11 PIN, CONNECTOR 9P
< DIODE >
D808 8-719-023-05 DIODE 11E2-TA2B
D818 8-719-023-05 DIODE 11E2-TA2B
************************************************************
* A-4403-012-A MAIN BOARD, COMPLETE (EX66: SP)
* A-4403-013-A MAIN BOARD, COMPLETE (EX66: AEP, UK)
* A-4398-060-A MAIN BOARD, COMPLETE (EX77: AEP, UK)
* A-4398-062-A MAIN BOARD, COMPLETE (EX77: HK, SP)
*********************
* 4-942-204-01 PLATE, GROUND
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C301 1-126-045-11 ELECT 2.2uF 20% 50V
C302 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C303 1-162-282-31 CERAMIC 100PF 10% 50V
C304 1-126-868-11 ELECT 47uF 20% 50V
C305 1-126-868-11 ELECT 47uF 20% 50V
C306 1-124-122-11 ELECT 100uF 20% 50V
C307 1-126-059-11 ELECT 10uF 20% 50V
C308 1-126-233-11 ELECT 22uF 20% 50V
C309 1-164-159-11 CERAMIC 0.1uF 50V
C310 1-136-163-00 FILM 0.068uF 5% 50V
C311 1-136-163-00 FILM 0.068uF 5% 50V
C312 1-126-868-11 ELECT 47uF 20% 50V
C318 1-162-200-31 CERAMIC 11PF 5% 50V
(AEP, UK)
C331 1-162-306-11 CERAMIC 0.01uF 20% 16V
(AEP, UK)
C340 1-126-059-11 ELECT 10uF 20% 50V
C351 1-126-045-11 ELECT 2.2uF 20% 50V
C352 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C353 1-162-282-31 CERAMIC 100PF 10% 50V
C354 1-126-868-11 ELECT 47uF 20% 50V
C355 1-126-868-11 ELECT 47uF 20% 50V
C356 1-124-122-11 ELECT 100uF 20% 50V
C357 1-126-059-11 ELECT 10uF 20% 50V
C358 1-162-200-31 CERAMIC 11PF 5% 50V
(AEP, UK)
C360 1-136-163-00 FILM 0.068uF 5% 50V
C361 1-136-163-00 FILM 0.068uF 5% 50V
C401 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
C402 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
C403 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
C451 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
C452 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
C453 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
C501 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C502 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C503 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C504 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C505 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C506 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C507 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C508 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C509 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C510 1-162-282-31 CERAMIC 100PF 10% 50V
C531 1-162-306-11 CERAMIC 0.01uF 20% 16V
C532 1-162-306-11 CERAMIC 0.01uF 20% 16V
C533 1-162-306-11 CERAMIC 0.01uF 20% 16V
C534 1-162-306-11 CERAMIC 0.01uF 20% 16V
SECTION 5
ELECTRICAL PARTS LIST
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
CONNECTOR MAIN
To Next Page
