Sony CDP-EX770 - ST-EX770 Service Manual Overview

ST-EX770
AEP Model
UK Model
SERVICE MANUAL
MICROFILM
Ref. No. Part No. Description
9-922-857-11
Sony Corporation
Home A&V Products Company
FM STEREO/FM-AM TIMER TUNER
98D001648-1D
Printed in Japan ©1998.4
Published by Quality Assurance Dept.
(Shibaura)
ST-EX770 is the tuner section in MHC-EX660 and DHC-EX770MD.
The mechanical and electorical specifications of ST-EX770 is almost
same as ST-EX77 AEP/UK model.
So this manual contains only the points which differ from ST-EX77.
For the informations not contained in this manual, please refer to the
ST-EX77 service manuals (9-960-933- ) previously issued.
•PARTS LIST(The difference between ST-EX77 and ST-EX770)
Page
* 6 4-985-904-11 PANEL(ST), BACK
51 X-4948-355-1 PANEL ASSY, FRONT
53 X-4947-762-1 BUTTON(TIMER) ASSY
54 4-985-890-01 BUTTON(MODE)
56 X-4948-356-1 BUTTON(MEMO) ASSY
(MEMORY, ST/MONO)
57 4-985-892-21 BUTTON(PLAY)
(TUNER/BAND, TUNING MODE)
61 4-985-925-01 KNOB(JOG)
Ref. No. Part No. Description
22
ST-EX77
ST-EX770
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
* 6 4-985-904-31 PANEL(ST), BACK
51 X-4949-865-1 PANEL ASSY, FRONT
53 X-4949-932-1 BUTTON(TIMER) ASSY
54 4-985-890-11 BUTTON(MODE)
56 X-4949-933-1 BUTTON(MEMO) ASSY
(MEMORY, ST/MONO)
57 4-985-892-41 BUTTON(PLAY)
(TUNER/BAND, TUNING MODE)
61 4-985-925-11 KNOB(JOG)
