– 24 –
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Abbreviation
HK: Hong Kong SP: Singapore
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
SECTION 6
ELECTRICAL PARTS LIST
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
When indicating parts by reference
number, please include the board.
* A-4398-064-A MAIN BOARD, COMPLETE (AEP, UK)
* A-4398-069-A MAIN BOARD, COMPLETE (HK, SP)
********************
* 4-924-988-11 PLATE (ST), GROUND
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C1 1-162-306-11 CERAMIC 0.01uF 20% 16V
C2 1-126-967-11 ELECT 47uF 20% 16V
C3 1-162-306-11 CERAMIC 0.01uF 20% 16V
C4 1-164-159-11 CERAMIC 0.1uF 50V
C5 1-164-159-11 CERAMIC 0.1uF 50V
C6 1-164-159-11 CERAMIC 0.1uF 50V
C7 1-126-967-11 ELECT 47uF 20% 16V
C8 1-162-306-11 CERAMIC 0.01uF 20% 16V
C9 1-162-306-11 CERAMIC 0.01uF 20% 16V
C10 1-162-306-11 CERAMIC 0.01uF 20% 16V
C11 1-126-964-11 ELECT 10uF 20% 50V
C12 1-126-959-11 ELECT 0.47uF 20% 50V
C13 1-126-960-11 ELECT 1uF 20% 50V
C14 1-126-960-11 ELECT 1uF 20% 50V
C15 1-126-964-11 ELECT 10uF 20% 50V
C16 1-126-964-11 ELECT 10uF 20% 50V
C17 1-126-964-11 ELECT 10uF 20% 50V
C18 1-126-964-11 ELECT 10uF 20% 50V
C19 1-136-158-00 FILM 0.027uF 5% 50V
C20 1-136-158-00 FILM 0.027uF 5% 50V
C21 1-137-436-11 FILM 0.0039uF 5% 50V
C22 1-137-436-11 FILM 0.0039uF 5% 50V
C23 1-126-960-11 ELECT 1uF 20% 50V
C24 1-162-294-31 CERAMIC 0.001uF 10% 50V
C25 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C26 1-126-967-11 ELECT 47uF 20% 16V
C27 1-126-962-11 ELECT 3.3uF 20% 50V
C28 1-164-159-11 CERAMIC 0.1uF 50V
C29 1-126-964-11 ELECT 10uF 20% 50V
C30 1-164-159-11 CERAMIC 0.1uF 50V
C32 1-102-527-11 CERAMIC 82PF 5% 50V
(AEP, UK)
C33 1-162-306-11 CERAMIC 0.01uF 20% 16V
C35 1-162-306-11 CERAMIC 0.01uF 20% 16V
C36 1-162-306-11 CERAMIC 0.01uF 20% 16V
C37 1-164-159-11 CERAMIC 0.1uF 50V
C38 1-162-198-31 CERAMIC 8.2PF 10% 50V
C40 1-162-306-11 CERAMIC 0.01uF 20% 16V
C41 1-162-306-11 CERAMIC 0.01uF 20% 16V
C43 1-162-294-31 CERAMIC 0.001uF 10% 50V
C44 1-164-159-11 CERAMIC 0.1uF 50V
C45 1-164-159-11 CERAMIC 0.1uF 50V
C47 1-164-095-11 CERAMIC 0.01uF 10% 16V
(HK, SP)
C51 1-102-518-11 CERAMIC 33PF 5% 50V
C52 1-102-514-11 CERAMIC 22PF 5% 50V
C53 1-126-964-11 ELECT 10uF 20% 50V
C54 1-164-159-11 CERAMIC 0.1uF 50V
C55 1-126-933-11 ELECT 100uF 20% 10V
C56 1-162-294-31 CERAMIC 0.001uF 10% 50V
C58 1-162-306-11 CERAMIC 0.01uF 20% 16V
C64 1-164-159-11 CERAMIC 0.1uF 50V
C65 1-126-933-11 ELECT 100uF 20% 16V
C67 1-162-306-11 CERAMIC 0.01uF 20% 16V
C71 1-126-961-11 ELECT 2.2uF 20% 50V
C73 1-164-159-11 CERAMIC 0.1uF 50V
C75 1-162-306-11 CERAMIC 0.01uF 20% 16V
C91 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C92 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C93 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP, UK)
C94 1-162-306-11 CERAMIC 0.01uF 20% 16V
(AEP, UK)
C95 1-164-159-11 CERAMIC 0.1uF 50V
C96 1-164-159-11 CERAMIC 0.1uF 50V
C97 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP, UK)
C98 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP, UK)
C111 1-126-942-61 ELECT 1000uF 20% 25V
C112 1-164-159-11 CERAMIC 0.1uF 50V
C113 1-126-933-11 ELECT 100uF 20% 10V
C121 1-104-666-11 ELECT 220uF 20% 25V
C122 1-104-666-11 ELECT 220uF 20% 25V
C123 1-126-952-11 ELECT 1000uF 20% 35V
C124 1-126-967-11 ELECT 47uF 20% 16V
C125 1-126-933-11 ELECT 100uF 20% 16V
C126 1-136-165-00 FILM 0.1uF 5% 50V
C141 1-128-563-11 ELECT 100uF 20% 100V
MAIN
