MICROFILM
CDP-EX77
COMPACT DISC PLAYER
SERVICE MANUAL
AEP Model
UK Model
E Model
CDP-EX77 is the CD player section
in MHC-EX66, DHC-EX77MD/MD77
Model Name Using Similar Mechanism HCD-MD5
CD Mechanism Type
CDM38A-5BD19
Base Unit Name BU-5BD19
Optical Pick-up Name KSS-213B/K-N
SPECIFICATIONS
System Compact disc and digital audio system
Laser Semiconductor laser (λ = 780 nm)
Emission duration: continuous
Laser output Max. 44.6 µW*
* This output is the value measured at a distance of
200 mm from the objective lens surface on the Op-
tical Pick-up Block with 7 mm aperture.
Frequency response 2 Hz to 20 kHz (± 0.5 dB)
CD OPTICAL DIGITAL OUT
(Square optical connector jack, rear panel)
Dimensions (w/h/d) incl. projecting parts and
controls: Approx. 280 × 122.5 × 347 mm
Mass Approx. 3.7 kg
Design and specifications are subject to change without notice.
