– 43 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R522 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R523 1-216-025-00 METAL GLAZE 100 5% 1/10W
R524 1-216-073-00 METAL CHIP 10K 5% 1/10W
R525 1-216-052-00 METAL CHIP 1.3K 5% 1/10W
R526 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R527 1-216-025-00 METAL GLAZE 100 5% 1/10W
R528 1-216-025-00 METAL GLAZE 100 5% 1/10W
R532 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R533 1-216-025-00 METAL GLAZE 100 5% 1/10W
R534 1-216-025-00 METAL GLAZE 100 5% 1/10W
R535 1-216-025-00 METAL GLAZE 100 5% 1/10W
R536 1-216-025-00 METAL GLAZE 100 5% 1/10W
R537 1-216-025-00 METAL GLAZE 100 5% 1/10W
R538 1-216-025-00 METAL GLAZE 100 5% 1/10W
R539 1-216-025-00 METAL GLAZE 100 5% 1/10W
R540 1-216-025-00 METAL GLAZE 100 5% 1/10W
R541 1-216-025-00 METAL GLAZE 100 5% 1/10W
R542 1-216-025-00 METAL GLAZE 100 5% 1/10W
R549 1-216-025-00 METAL GLAZE 100 5% 1/10W
R550 1-216-025-00 METAL GLAZE 100 5% 1/10W
R552 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R553 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R554 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R555 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R556 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R557 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R558 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R559 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R560 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R561 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R562 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R563 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R564 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R565 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R566 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R567 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R568 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R569 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R570 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R571 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R572 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R573 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R574 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R575 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R576 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R577 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R578 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R579 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R580 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R581 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R582 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R583 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R584 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R585 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R591 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R592 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R594 1-216-039-00 METAL CHIP 390 5% 1/10W
R595 1-216-039-00 METAL CHIP 390 5% 1/10W
R596 1-249-425-11 CARBON 4.7K 5% 1/4W
R597 1-249-425-11 CARBON 4.7K 5% 1/4W
R598 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R599 1-216-049-11 METAL GLAZE 1K 5% 1/10W
< SWITCH >
S501 1-554-303-21 SWITCH, TACTILE (LOOP)
S502 1-762-196-21 SWITCH, TACT (ENTER)
S503 1-762-196-21 SWITCH, TACT (p)
S504 1-762-196-21 SWITCH, TACT ())
S505 1-762-196-21 SWITCH, TACT (0)
S506 1-762-196-21 SWITCH, TACT (fl)
S511 1-762-196-21 SWITCH, TACT (PROGRAM)
S512 1-762-196-21 SWITCH, TACT (SHUFFLE)
S513 1-762-196-21 SWITCH, TACT (CONTINUE)
S514 1-762-196-21 SWITCH, TACT (REPEAT)
S515 1-762-196-21 SWITCH, TACT (TIME)
S516 1-762-196-21 SWITCH, TACT (CLEAR)
S521 1-467-938-11 ENCODER, ROTARY (= SELECTOR +)
< VIBRATOR >
X501 1-579-233-11 VIBRATOR, CERAMIC (5MHz)
************************************************************
* 1-663-321-11 LOADING BOARD
**************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN801 1-695-093-11 SOCKET, CONNECTOR 9P
< DIODE >
D801 8-719-109-93 DIODE RD6.2ESB2
D805 8-719-987-63 DIODE 1N4148M
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN)
************************************************************
* A-4699-658-A MAIN BOARD, COMPLETE
**********************
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C101 1-162-306-11 CERAMIC 0.01uF 20% 16V
C102 1-126-933-11 ELECT 100uF 20% 16V
C103 1-106-351-00 MYLAR 2200PF 5% 200V
C104 1-106-351-00 MYLAR 2200PF 5% 200V
MAINLOADINGDISPLAY
