Ref. No. Part No. Description Remark
MISCELLANEOUS
*************
8 1-777-862-11 WIRE (FLAT TYPE) (19 CORE)
64 1-777-861-11 WIRE (FLAT TYPE) (29 CORE)
66 1-777-860-11 WIRE (FLAT TYPE) (9 CORE)
255 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
* 262 1-452-879-11 MAGNET
! 305 8-848-367-11 OPTICAL PICK-UP KSS-213B/K-N
306 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
M101 X-4917-523-4 BASE (OUTSERT) ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M701 A-4660-586-A MOTOR ASSY (TURN)
M801 A-4660-926-A MOTOR (CDM) ASSY (SPINDLE)
S851 1-473-335-11 ENCODER, ROTARY
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#3 7-685-872-09 SCREW +BVTT 3X8 (S)
#4 7-621-775-10 SCREW +B 2.6X4
#5 7-621-255-15 SCREW +P 2X3
