Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
32
CDP-S3
MAIN
D513 8-719-024-99 DIODE 11ES2-NTA2B
D514 8-719-024-99 DIODE 11ES2-NTA2B
D515 8-719-024-99 DIODE 11ES2-NTA2B
< FERRITE BEAD >
FB305 1-412-473-21 INDUCTOR 0uH
FB310 1-412-473-21 INDUCTOR 0uH
FB311 1-412-473-21 INDUCTOR 0uH
FB312 1-412-473-21 INDUCTOR 0uH
FB313 1-412-473-21 INDUCTOR 0uH
FB314 1-412-473-21 INDUCTOR 0uH
FB315 1-412-473-21 INDUCTOR 0uH
FB410 1-412-473-21 INDUCTOR 0uH
FB416 1-412-473-21 INDUCTOR 0uH
< IC >
IC102 8-749-019-13 IC TOTX140 (OPTICAL OUT TO ST-S3/S5)
IC401 8-759-827-46 IC M30620MAA-B31FP
IC402 8-759-269-09 IC SN74HCT04ANS-E05
IC502 8-759-158-62 IC TA78057S
IC503 8-759-071-48 IC TA7807S
< RESISTOR >
JW98 1-247-807-31 CARBON 100 5% 1/4W
JW99 1-247-807-31 CARBON 100 5% 1/4W
< COIL >
L125 1-410-336-11 INDUCTOR 220uH
L310 1-410-467-11 INDUCTOR 5.6uH
< TRANSISTOR >
Q501 8-729-049-79 TRANSISTOR RT1P137S-TP
Q502 8-729-900-80 TRANSISTOR BA1A4M-TP
< RESISTOR >
R123 1-247-807-31 CARBON 100 5% 1/4W
R132 1-247-876-11 CARBON 75K 5% 1/4W
R133 1-247-876-11 CARBON 75K 5% 1/4W
R134 1-249-417-11 CARBON 1K 5% 1/4W
R401 1-247-807-31 CARBON 100 5% 1/4W
R402 1-247-807-31 CARBON 100 5% 1/4W
R403 1-247-807-31 CARBON 100 5% 1/4W
R409 1-249-429-11 CARBON 10K 5% 1/4W
R411 1-247-807-31 CARBON 100 5% 1/4W
R412 1-249-429-11 CARBON 10K 5% 1/4W
R413 1-249-411-11 CARBON 330 5% 1/4W
R417 1-249-429-11 CARBON 10K 5% 1/4W
R419 1-247-807-31 CARBON 100 5% 1/4W
R424 1-249-421-11 CARBON 2.2K 5% 1/4W
R425 1-249-425-11 CARBON 4.7K 5% 1/4W
R426 1-247-887-00 CARBON 220K 5% 1/4W
R427 1-249-425-11 CARBON 4.7K 5% 1/4W
R428 1-249-441-11 CARBON 100K 5% 1/4W
R429 1-247-807-31 CARBON 100 5% 1/4W
R430 1-247-807-31 CARBON 100 5% 1/4W
R432 1-247-807-31 CARBON 100 5% 1/4W
R433 1-247-807-31 CARBON 100 5% 1/4W
C122 1-161-494-00 CERAMIC 0.022uF 25V
C124 1-164-159-11 CERAMIC 0.1uF 50V
C125 1-126-923-11 ELECT 220uF 20% 10V
C251 1-161-494-00 CERAMIC 0.022uF 25V
C255 1-161-494-00 CERAMIC 0.022uF 25V
C260 1-161-494-00 CERAMIC 0.022uF 25V
C261 1-161-494-00 CERAMIC 0.022uF 25V
C301 1-126-959-11 ELECT 0.47uF 20% 50V
C302 1-162-600-11 CERAMIC 0.0047uF 20% 16V
C303 1-162-306-11 CERAMIC 0.01uF 20% 16V
C304 1-161-494-00 CERAMIC 0.022uF 25V
C310 1-161-494-00 CERAMIC 0.022uF 25V
C311 1-162-306-11 CERAMIC 0.01uF 20% 16V
C313 1-162-286-31 CERAMIC 220PF 10% 50V
C314 1-162-282-31 CERAMIC 100PF 10% 50V
C315 1-162-282-31 CERAMIC 100PF 10% 50V
C316 1-162-282-31 CERAMIC 100PF 10% 50V
C317 1-162-282-31 CERAMIC 100PF 10% 50V
C318 1-162-282-31 CERAMIC 100PF 10% 50V
C319 1-162-282-31 CERAMIC 100PF 10% 50V
C320 1-162-306-11 CERAMIC 0.01uF 20% 16V
C321 1-161-494-00 CERAMIC 0.022uF 25V
C401 1-161-494-00 CERAMIC 0.022uF 25V
C411 1-126-960-11 ELECT 1uF 20% 50V
C416 1-126-964-11 ELECT 10uF 20% 50V
C425 1-162-282-31 CERAMIC 100PF 10% 50V
C427 1-162-282-31 CERAMIC 100PF 10% 50V
C462 1-161-494-00 CERAMIC 0.022uF 25V
C463 1-126-964-11 ELECT 10uF 20% 50V
C498 1-161-494-00 CERAMIC 0.022uF 25V
C499 1-161-494-00 CERAMIC 0.022uF 25V
C500 1-164-159-11 CERAMIC 0.1uF 50V
C501 1-126-937-11 ELECT 4700uF 20% 16V
C513 1-126-935-11 ELECT 470uF 20% 10V
C521 1-164-159-11 CERAMIC 0.1uF 50V
C522 1-126-935-11 ELECT 470uF 20% 10V
C523 1-126-934-11 ELECT 220uF 20% 10V
C524 1-126-934-11 ELECT 220uF 20% 10V
C531 1-164-159-11 CERAMIC 0.1uF 50V
C532 1-126-935-11 ELECT 470uF 20% 10V
< CONNECTOR >
* CN101 1-568-419-11 PIN, CONNECTOR 9P
CN102 1-568-373-11 PIN, CONNECTOR 8P
CN103 1-566-859-11 SOCKET, CONNECTOR 15P
(SYSTEM CONTROL 5 TO TC-S3)
CN301 1-568-838-11 CONNECTOR, FFC 21P
* CN401 1-568-936-11 PIN, CONNECTOR 9P
< DIODE >
D105 8-719-911-19 DIODE 1SS133T-72
D123 8-719-982-96 DIODE MTZJ-T-72-2.2A
D501 8-719-024-99 DIODE 11ES2-NTA2B
D502 8-719-024-99 DIODE 11ES2-NTA2B
D503 8-719-024-99 DIODE 11ES2-NTA2B
D504 8-719-024-99 DIODE 11ES2-NTA2B
D511 8-719-024-99 DIODE 11ES2-NTA2B
D512 8-719-024-99 DIODE 11ES2-NTA2B
