Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
33
CDP-S3
R435 1-247-807-31 CARBON 100 5% 1/4W
R436 1-247-807-31 CARBON 100 5% 1/4W
R437 1-247-807-31 CARBON 100 5% 1/4W
R438 1-247-807-31 CARBON 100 5% 1/4W
R440 1-247-807-31 CARBON 100 5% 1/4W
R441 1-249-429-11 CARBON 10K 5% 1/4W
R442 1-247-807-31 CARBON 100 5% 1/4W
R443 1-247-807-31 CARBON 100 5% 1/4W
R444 1-247-807-31 CARBON 100 5% 1/4W
R445 1-247-807-31 CARBON 100 5% 1/4W
R446 1-247-807-31 CARBON 100 5% 1/4W
R447 1-247-807-31 CARBON 100 5% 1/4W
R448 1-247-807-31 CARBON 100 5% 1/4W
R449 1-247-807-31 CARBON 100 5% 1/4W
R450 1-247-807-31 CARBON 100 5% 1/4W
R451 1-247-807-31 CARBON 100 5% 1/4W
R452 1-247-807-31 CARBON 100 5% 1/4W
R453 1-247-807-31 CARBON 100 5% 1/4W
R456 1-249-429-11 CARBON 10K 5% 1/4W
R457 1-249-429-11 CARBON 10K 5% 1/4W
R459 1-247-807-31 CARBON 100 5% 1/4W
R460 1-249-429-11 CARBON 10K 5% 1/4W
R465 1-249-407-11 CARBON 150 5% 1/4W
R469 1-249-407-11 CARBON 150 5% 1/4W
R473 1-249-407-11 CARBON 150 5% 1/4W
R477 1-249-407-11 CARBON 150 5% 1/4W
R480 1-249-441-11 CARBON 100K 5% 1/4W
R481 1-249-407-11 CARBON 150 5% 1/4W
R482 1-249-429-11 CARBON 10K 5% 1/4W
R483 1-249-429-11 CARBON 10K 5% 1/4W
R484 1-247-807-31 CARBON 100 5% 1/4W
R485 1-247-807-31 CARBON 100 5% 1/4W
R486 1-247-807-31 CARBON 100 5% 1/4W
R487 1-247-807-31 CARBON 100 5% 1/4W
R489 1-247-807-31 CARBON 100 5% 1/4W
R490 1-247-807-31 CARBON 100 5% 1/4W
R491 1-247-807-31 CARBON 100 5% 1/4W
R492 1-249-425-11 CARBON 4.7K 5% 1/4W
R493 1-249-407-11 CARBON 150 5% 1/4W
R494 1-247-807-31 CARBON 100 5% 1/4W
R495 1-247-807-31 CARBON 100 5% 1/4W
R496 1-249-429-11 CARBON 10K 5% 1/4W
R497 1-247-807-31 CARBON 100 5% 1/4W
R500 1-249-429-11 CARBON 10K 5% 1/4W
< VIBRATOR >
X401 1-781-107-21 VIBRATOR, CERAMIC (16MHz)
**************************************************************
1-678-461-11 MOTOR BOARD
*************
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30% 16V
**************************************************************
1-680-995-11 PANEL (L) BOARD
***************
< LED >
D701 8-719-057-97 LED SEL5923A-TP15 (X)
D702 8-719-058-03 LED SEL5423E-TP15 (N)
D703 8-719-057-97 LED SEL5923A-TP15 (3)
D704 8-719-057-97 LED SEL5923A-TP15 (2)
D705 8-719-057-97 LED SEL5923A-TP15 (1)
< RESISTOR >
R710 1-249-410-11 CARBON 270 5% 1/4W
R711 1-249-411-11 CARBON 330 5% 1/4W
R712 1-249-413-11 CARBON 470 5% 1/4W
R713 1-249-414-11 CARBON 560 5% 1/4W
R714 1-249-415-11 CARBON 680 5% 1/4W
R715 1-249-417-11 CARBON 1K 5% 1/4W
R716 1-249-418-11 CARBON 1.2K 5% 1/4W
< SWITCH >
S711 1-771-410-21 SWITCH, TACTILE (m)
S712 1-771-410-21 SWITCH, TACTILE (M)
S713 1-771-410-21 SWITCH, TACTILE (>)
S714 1-771-410-21 SWITCH, TACTILE (.)
S715 1-771-410-21 SWITCH, TACTILE (x)
S716 1-771-410-21 SWITCH, TACTILE (X)
S717 1-771-410-21 SWITCH, TACTILE (N)
**************************************************************
1-680-996-11 PANEL (R) BOARD
***************
< RESISTOR >
R700 1-249-410-11 CARBON 270 5% 1/4W
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-413-11 CARBON 470 5% 1/4W
R703 1-249-414-11 CARBON 560 5% 1/4W
R704 1-249-415-11 CARBON 680 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W
R706 1-249-418-11 CARBON 1.2K 5% 1/4W
R707 1-249-420-11 CARBON 1.8K 5% 1/4W
< SWITCH >
S701 1-771-410-21 SWITCH, TACTILE (DISC 3)
S702 1-771-410-21 SWITCH, TACTILE (DISC 2)
S703 1-771-410-21 SWITCH, TACTILE (DISC1)
S704 1-771-410-21 SWITCH, TACTILE (Z (DISC 1))
S705 1-771-410-21 SWITCH, TACTILE (Z (DISC 2))
S706 1-771-410-21 SWITCH, TACTILE (Z (DISC 3))
S707 1-771-410-21 SWITCH, TACTILE (REPEAT)
S708 1-771-410-21 SWITCH, TACTILE (PLAY MODE)
**************************************************************
1-678-457-11 TRAY SENSOR BOARD
******************
< CAPACITOR >
C731 1-164-159-11 CERAMIC 0.1uF 50V
MAIN MOTOR PANEL (L) PANEL (R) TRAY SENSOR
