Sony CDP-S3 - Tray Sensor Board Electrical Parts

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
34
CDP-S3
< PHOTO SENSOR >
IC731 8-749-081-01 PHOTO SENSOR DG-264
IC732 8-749-081-01 PHOTO SENSOR DG-264
IC733 8-749-081-01 PHOTO SENSOR DG-264
< RESISTOR >
R731 1-247-876-11 CARBON 75K 5% 1/4W
R732 1-249-408-11 CARBON 180 5% 1/4W
R733 1-247-876-11 CARBON 75K 5% 1/4W
R734 1-249-408-11 CARBON 180 5% 1/4W
R735 1-247-876-11 CARBON 75K 5% 1/4W
R736 1-249-408-11 CARBON 180 5% 1/4W
***********************************************************
MISCELLANEOUS
**************
9 1-823-055-11 WIRE (FLAT TYPE) (21 CORE)
11 1-757-633-11 CORD (WITH CONNECTOR) 17P
571 X-4952-971-2 MOTOR ASSY
605 1-757-710-11 WIRE (FLAT TYPE) (16 CORE)
0606 A-4735-188-A BU-30 (60) ASSY
M721 1-541-632-12 MOTOR, DC (LOADING)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
TRAY SENSOR
