Sony CDP-XE570 - Electrical Parts List - Other Boards; Display, Headphone, Key Board Components

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
27
CDP-XE570
R153 1-216-864-11 METAL CHIP 0 5% 1/16W
R155 1-216-836-11 METAL CHIP 18K 5% 1/16W
R171 1-218-720-11 METAL CHIP 15K 0.5% 1/16W
R172 1-218-720-11 METAL CHIP 15K 0.5% 1/16W
R173 1-218-720-11 METAL CHIP 15K 0.5% 1/16W
R174 1-216-809-11 METAL CHIP 100 5% 1/16W
R181 1-218-720-11 METAL CHIP 15K 0.5% 1/16W
R182 1-218-720-11 METAL CHIP 15K 0.5% 1/16W
R183 1-218-720-11 METAL CHIP 15K 0.5% 1/16W
R184 1-216-809-11 METAL CHIP 100 5% 1/16W
R191 1-216-817-11 METAL CHIP 470 5% 1/16W
R192 1-216-797-11 METAL CHIP 10 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB101 1-233-576-11 RES, CHIP NETWORK 100
RB102 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF(LIMIT)
< VIBRATOR >
X191 1-767-408-21 VIBRATOR, CRYSTAL 16.9344MHz
************************************************************
A-4725-621-A DISPLAY BOARD,COMPLETE
***********************
* 4-929-709-31 GUIDE (FL TUBE)
< CAPACITOR >
C502 1-164-159-11 CERAMIC 0.1uF 50V
C503 1-126-382-11 ELECT 100uF 20.00% 10V
C505 1-164-159-11 CERAMIC 0.1uF 50V
C506 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN501 1-784-780-11 CONNECTOR, FFC 19P
< FILTER >
FL501 1-517-740-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC501 8-752-921-33 IC CXP82832-033Q
IC502 8-759-459-86 IC NJL64H400A(REMOTE SENSOR)
< TRANSISTOR >
Q501 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q502 8-729-029-66 TRANSISTOR DTC114ESA-TP
< RESISTOR >
R501 1-249-427-11 CARBON 6.8K 5% 1/4W F
R502 1-249-415-11 CARBON 680 5% 1/4W F
R503 1-249-417-11 CARBON 1K 5% 1/4W F
R504 1-249-419-11 CARBON 1.5K 5% 1/4W F
R505 1-249-421-11 CARBON 2.2K 5% 1/4W F
R511 1-249-427-11 CARBON 6.8K 5% 1/4W F
R512 1-249-415-11 CARBON 680 5% 1/4W F
R513 1-249-417-11 CARBON 1K 5% 1/4W F
R514 1-249-419-11 CARBON 1.5K 5% 1/4W F
R521 1-249-427-11 CARBON 6.8K 5% 1/4W F
R531 1-249-441-11 CARBON 100K 5% 1/4W
R532 1-249-441-11 CARBON 100K 5% 1/4W
R535 1-249-427-11 CARBON 6.8K 5% 1/4W F
R536 1-249-427-11 CARBON 6.8K 5% 1/4W F
R537 1-249-429-11 CARBON 10K 5% 1/4W
R539 1-249-429-11 CARBON 10K 5% 1/4W
R541 1-247-807-31 CARBON 100 5% 1/4W
R542 1-247-807-31 CARBON 100 5% 1/4W
R551 1-249-415-11 CARBON 680 5% 1/4W F
R552 1-249-417-11 CARBON 1K 5% 1/4W F
< SWITCH >
S501 1-771-349-21 SWITCH, KEYBOARD(x)
S502 1-771-349-21 SWITCH, KEYBOARD(X)
S503 1-771-349-21 SWITCH, KEYBOARD(G)
S504 1-771-349-21 SWITCH, KEYBOARD(OPEN/CLOSE A)
S511 1-771-349-21 SWITCH, KEYBOARD(M)
S512 1-771-349-21 SWITCH, KEYBOARD(m)
S531 1-475-543-11 ENCODER, ROTARY(l AMS L)
< VIBRATOR >
X501 1-579-125-11 VIBRATOR, CERAMIC 8MHz
************************************************************
1-681-127-11 HEADPHONE BOARD
*****************
< CAPACITOR >
C402 1-162-291-31 CERAMIC 560PF 10.00% 50V
C403 1-162-291-31 CERAMIC 560PF 10.00% 50V
< JACK >
J401 1-770-307-11 JACK (LARGE TYPE)(PHONES)
< COIL >
L402 1-412-911-11 FERRITE 0uH
L403 1-412-911-11 FERRITE 0uH
************************************************************
1-681-125-11 KEY BOARD
**********
< RESISTOR >
R522 1-249-415-11 CARBON 680 5% 1/4W F
R523 1-249-417-11 CARBON 1K 5% 1/4W F
R524 1-249-419-11 CARBON 1.5K 5% 1/4W F
R525 1-249-421-11 CARBON 2.2K 5% 1/4W F
R526 1-247-843-11 CARBON 3.3K 5% 1/4W
R527 1-249-427-11 CARBON 6.8K 5% 1/4W F
R528 1-249-431-11 CARBON 15K 5% 1/4W
BD DISPLAY KEYHEADPHONE
