Sony CDP-XE570 - Electrical Parts List - Miscellaneous and Hardware; Main;Power SW Board Resistors; Hardware and Accessories

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
29
CDP-XE570
< JACK >
J621 1-779-655-21 JACK (SMALL TYPE) (2 GANG)(CONTROL A1II )
J681 1-785-868-11 JACK, PIN 2P(ANALOG OUT)
< COIL >
L651 1-414-151-11 INDUCTOR 470uH
< TRANSISTOR >
Q621 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q642 8-729-041-38 TRANSISTOR 2SB1241TV2Q
Q681 8-729-029-56 TRANSISTOR DTA144ESA-TP
Q682 8-729-922-37 TRANSISTOR 2SD2144S-TP-UVW
Q683 8-729-922-37 TRANSISTOR 2SD2144S-TP-UVW
Q691 8-729-029-56 TRANSISTOR DTA144ESA-TP
Q692 8-729-922-37 TRANSISTOR 2SD2144S-TP-UVW
Q693 8-729-922-37 TRANSISTOR 2SD2144S-TP-UVW
< RESISTOR >
R611 1-249-429-11 CARBON 10K 5% 1/4W
R612 1-249-411-11 CARBON 330 5% 1/4W
R624 1-249-393-11 CARBON 10 5% 1/4W F
R625 1-249-429-11 CARBON 10K 5% 1/4W
R626 1-249-425-11 CARBON 4.7K 5% 1/4W F
R631 1-249-427-11 CARBON 6.8K 5% 1/4W F
R632 1-215-421-00 METAL 1K 1% 1/4W
R641 1-249-432-11 CARBON 18K 5% 1/4W
R642 1-249-432-11 CARBON 18K 5% 1/4W
R646 1-249-432-11 CARBON 18K 5% 1/4W
R647 1-247-807-31 CARBON 100 5% 1/4W
R648 1-247-807-31 CARBON 100 5% 1/4W
R651 1-247-807-31 CARBON 100 5% 1/4W
R652 1-247-807-31 CARBON 100 5% 1/4W
R653 1-247-807-31 CARBON 100 5% 1/4W
R681 1-249-441-11 CARBON 100K 5% 1/4W
R682 1-249-419-11 CARBON 1.5K 5% 1/4W F
R683 1-249-419-11 CARBON 1.5K 5% 1/4W F
R691 1-249-441-11 CARBON 100K 5% 1/4W
R692 1-249-419-11 CARBON 1.5K 5% 1/4W F
R693 1-249-419-11 CARBON 1.5K 5% 1/4W F
R804 1-215-445-00 METAL 10K 1% 1/4W
R805 1-249-429-11 CARBON 10K 5% 1/4W
R806 1-215-445-00 METAL 10K 1% 1/4W
R807 1-215-425-00 METAL 1.5K 1% 1/4W
R808 1-215-425-00 METAL 1.5K 1% 1/4W
R809 1-249-441-11 CARBON 100K 5% 1/4W
R810 1-249-414-11 CARBON 560 5% 1/4W F
R812 1-247-807-31 CARBON 100 5% 1/4W
R821 1-249-403-11 CARBON 68 5% 1/4W F
R904 1-215-445-00 METAL 10K 1% 1/4W
R905 1-249-429-11 CARBON 10K 5% 1/4W
R906 1-215-445-00 METAL 10K 1% 1/4W
R907 1-215-425-00 METAL 1.5K 1% 1/4W
R908 1-215-425-00 METAL 1.5K 1% 1/4W
R909 1-249-441-11 CARBON 100K 5% 1/4W
R910 1-249-414-11 CARBON 560 5% 1/4W F
R912 1-247-807-31 CARBON 100 5% 1/4W
R921 1-249-403-11 CARBON 68 5% 1/4W F
************************************************************
1-681-126-11 POWER SW BOARD
****************
< CAPACITOR >
0 C621 1-113-924-11 CERAMIC 0.0047uF 20.00% 250V
< CONNECTOR >
* CN601 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
CN602 1-564-321-00 PIN, CONNECTOR 2P
< SWITCH >
0 S601 1-762-581-11 SWITCH, AC POWER PUSH (1 KEY) (POWER)
************************************************************
MISCELLANEOUS
**************
10 1-773-114-11 WIRE (FLAT TYPE) (19 CORE)
17 1-773-149-11 WIRE (FLAT TYPE) (21 CORE)
0 18 1-575-651-21 CORD, POWER
0 26 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
101 1-452-925-21 MAGNET ASSY
104 1-541-632-11 MOTOR, DC (LOADING)
0 151 1-796-033-11 OPTICAL PICK UP (PXR-104X)
152 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
M102 1-541-353-11 MOTOR (SLED)
0 T601 1-437-258-11 TRANSFORMER, POWER
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-418-765-11 REMOTE COMMANDER (RM-DX740)
1-776-263-11 CORD, CONNECTION
4-233-601-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH)(AEP)
4-233-601-21 MANUAL, INSTRUCTION (GERMAN,SPANISH,
DUTCH,SWEDISH,ITALIAN,POLISH)(AEP)
4-233-601-71 MANUAL, INSTRUCTION (ENGLISH)(UK)
4-983-956-01 COVER, BATTERY
************************************************************
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
MAIN POWER SW
*************
HARDWARE LIST
*************
#1 7-621-775-10 SCREW +B 2.6X4
#2 4-951-620-01 SCREW (2.6X8), +BVTP
