— 33 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R819 1-249-429-11 CARBON 10K 5% 1/4W
R827 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S801 1-554-303-21 SWITCH, TACTILE (ENTER)
S802 1-554-303-21 SWITCH, TACTILE (CLEAR)
S803 1-554-303-21 SWITCH, TACTILE (CHECK)
S804 1-554-303-21 SWITCH, TACTILE ())
S805 1-554-303-21 SWITCH, TACTILE (0)
S806 1-554-303-21 SWITCH, TACTILE (p)
S807 1-554-303-21 SWITCH, TACTILE (P)
S808 1-554-303-21 SWITCH, TACTILE (·)
S809 1-554-303-21 SWITCH, TACTILE (§ OPEN/CLOSE)
S810 1-473-452-11 ENCODER, ROTARY (≠ AMS ±)
< VIBRATOR >
X801 1-577-082-11 VIBRATOR, CERAMIC (4MHz)
**************************************************************
* 1-658-820-11 HP BOARD (AEP,G)
***************
< CAPACITOR >
C471 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP,G)
C571 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP,G)
C752 1-164-159-21 CERAMIC 0.1uF 50V
(AEP,G)
< DIODE >
D701 8-719-815-85 DIODE 1S1585 (AEP,G)
D702 8-719-815-85 DIODE 1S1585 (AEP,G)
< JACK >
J751 1-770-307-11 JACK (LARGE TYPE)(PHONES)(AEP,G)
< COIL >
L701 1-424-122-11 FILTER, NOISE (AEP,G)
L702 1-424-122-11 FILTER, NOISE (AEP,G)
L703 1-424-122-11 FILTER, NOISE (AEP,G)
**************************************************************
* 1-658-818-11 KEY BOARD
**********
< RESISTOR >
R820 1-249-415-11 CARBON 680 5% 1/4W
R821 1-249-417-11 CARBON 1K 5% 1/4W
R822 1-249-421-11 CARBON 2.2K 5% 1/4W
R823 1-249-423-11 CARBON 3.3K 5% 1/4W
R824 1-249-427-11 CARBON 6.8K 5% 1/4W
R825 1-249-431-11 CARBON 15K 5% 1/4W
R826 1-249-419-11 CARBON 1.5K 5% 1/4W
< SWITCH >
S820 1-554-303-21 SWITCH, TACTILE (TIME)
S821 1-554-303-21 SWITCH, TACTILE (FADER)
S822 1-554-303-21 SWITCH, TACTILE (REPEAT)
S823 1-554-303-21 SWITCH, TACTILE (EDIT/TIME FADE)
S824 1-554-303-21 SWITCH, TACTILE (PEAK SEARCH)
S825 1-554-303-21 SWITCH, TACTILE (AUTO SPACE)
S826 1-554-303-21 SWITCH, TACTILE (MUSIC SCAN)
S827 1-554-118-00 SWITCH, PUSH (1 KEY)(POWER)
S828 1-554-303-21 SWITCH, TACTILE (PLAY MODE)
**************************************************************
* 1-658-710-11 LOADING BOARD
**************
**************************************************************
* A-4673-777-A MAIN BOARD, COMPLETE (AEP,G)
***************************
* A-4673-908-A MAIN BOARD, COMPLETE (UK)
************************
* 3-309-144-21 HEAT SINK
7-685-871-01 SCREW +BVTT 3X6 (S)
* 1-537-738-21 TERMINAL, EARTH
< CAPACITOR >
C301 1-164-159-21 CERAMIC 0.1uF 50V
C303 1-162-306-11 CERAMIC 0.01uF 30% 16V
C304 1-161-494-00 CERAMIC 0.022uF 25V
C305 1-164-159-21 CERAMIC 0.1uF 50V
C306 1-126-962-11 ELECT 3.3uF 20% 50V
C307 1-104-665-11 ELECT 100uF 20% 16V
C321 1-162-290-31 CERAMIC 470PF 10% 50V
C322 1-164-159-21 CERAMIC 0.1uF 50V
C323 1-126-024-11 ELECT 220uF 20% 25V
C324 1-164-159-21 CERAMIC 0.1uF 50V
C325 1-164-159-21 CERAMIC 0.1uF 50V
C326 1-126-024-11 ELECT 220uF 20% 25V
C327 1-164-159-21 CERAMIC 0.1uF 50V
C331 1-102-508-91 CERAMIC 10PF 0.5PF 50V
C332 1-102-951-00 CERAMIC 15PF 5% 50V
C333 1-164-159-21 CERAMIC 0.1uF 50V
C334 1-124-994-11 ELECT 100uF 20% 10V
C361 1-126-026-11 ELECT 470uF 20% 25V
C392 1-164-159-21 CERAMIC 0.1uF 50V
C393 1-164-159-21 CERAMIC 0.1uF 50V
C394 1-164-159-21 CERAMIC 0.1uF 50V
C395 1-164-159-21 CERAMIC 0.1uF 50V
C396 1-164-159-21 CERAMIC 0.1uF 50V
(AEP,G)
MAIN
LOADING
KEY
DISPLAY
HP
