— 34 —
MAIN
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C401 1-164-159-21 CERAMIC 0.1uF 50V
C402 1-124-994-11 ELECT 100uF 20% 10V
C409 1-102-816-00 CERAMIC 120PF 5% 50V
C410 1-102-816-00 CERAMIC 120PF 5% 50V
C411 1-102-816-00 CERAMIC 120PF 5% 50V
C412 1-106-343-00 MYLAR 1000PF 5% 200V
C413 1-130-484-00 MYLAR 0.012uF 5% 50V
C415 1-128-200-11 ELECT 47uF 20% 63V
C416 1-130-468-00 MYLAR 560PF 5% 50V
C451 1-161-494-00 CERAMIC 0.022uF 25V
(AEP,G)
C452 1-161-494-00 CERAMIC 0.022uF 25V
(AEP,G)
C454 1-162-290-31 CERAMIC 470PF 10% 50V
(AEP,G)
C501 1-164-159-21 CERAMIC 0.1uF 50V
C502 1-124-994-11 ELECT 100uF 20% 10V
C509 1-102-816-00 CERAMIC 120PF 5% 50V
C510 1-102-816-00 CERAMIC 120PF 5% 50V
C511 1-102-816-00 CERAMIC 120PF 5% 50V
C512 1-106-343-00 MYLAR 1000PF 5% 200V
C513 1-130-484-00 MYLAR 0.012uF 5% 50V
C515 1-128-200-11 ELECT 47uF 20% 63V
C516 1-130-468-00 MYLAR 560PF 5% 50V
C544 1-162-290-31 CERAMIC 470PF 10% 50V
(AEP,G)
C911 1-128-198-11 ELECT 22uF 20% 63V
C915 1-124-907-11 ELECT 10uF 20% 50V
C920 1-162-294-31 CERAMIC 0.001uF 10% 50V
C921 1-126-962-11 ELECT 3.3uF 20% 50V
C922 1-164-159-21 CERAMIC 0.1uF 50V
C923 1-161-494-00 CERAMIC 0.022uF 25V
C924 1-161-494-00 CERAMIC 0.022uF 25V
C930 1-126-942-61 ELECT 1000uF 20% 16V
(AEP,G)
C930 1-124-360-00 ELECT 1000uF 20% 16V (UK)
C931 1-126-944-11 ELECT 3300uF 20% 16V
(AEP,G)
C931 1-124-523-11 ELECT 4700uF 20% 16V (UK)
C932 1-104-665-11 ELECT 100uF 20% 16V
C935 1-126-011-11 ELECT 330uF 20% 16V
C937 1-130-495-00 MYLAR 0.1uF 5% 50V
(AEP,G)
C937 1-136-850-11 FILM 0.1uF 5% 63V (UK)
C939 1-126-049-11 ELECT 22uF 20% 50V
C941 1-124-473-11 ELECT 1000uF 20% 10V
C942 1-104-666-11 ELECT 220uF 20% 10V
C943 1-162-294-31 CERAMIC 0.001uF 10% 50V
C944 1-130-495-00 MYLAR 0.1uF 5% 50V
(AEP,G)
C944 1-136-850-11 FILM 0.1uF 5% 63V (UK)
< CONNECTOR >
* CN301 1-568-839-11 SOCKET, CONNECTOR 23P
* CN302 1-568-839-11 SOCKET, CONNECTOR 23P
CN651 1-506-468-11 PIN, CONNECTOR 3P (AEP,G)
CN951 1-766-269-11 PIN, CONNECTOR (PC BOARD) 7P
< DIODE >
D301 8-719-010-34 DIODE UZ-4.7BSC
D303 8-719-911-19 DIODE 1SS119
D910 8-719-200-82 DIODE 11ES2
D911 8-719-911-19 DIODE 1SS119
D912 8-719-982-15 DIODE MTZJ-27B
D913 8-719-110-03 DIODE RD7.5ESB2
D930 8-719-200-82 DIODE 11ES2 (AEP,G)
D930 8-719-210-21 DIODE 11EQS04 (UK)
D931 8-719-200-82 DIODE 11ES2 (AEP,G)
D931 8-719-210-21 DIODE 11EQS04 (UK)
D932 8-719-200-82 DIODE 11ES2 (AEP,G)
D932 8-719-210-21 DIODE 11EQS04 (UK)
D933 8-719-200-82 DIODE 11ES2 (AEP,G)
D933 8-719-210-21 DIODE 11EQS04 (UK)
D934 8-719-911-19 DIODE 1SS119
D935 8-719-921-40 DIODE MTZJ-4.7C
D936 8-719-911-19 DIODE 1SS119
D937 8-719-115-38 DIODE RD5.1JS-T1B2
< IC >
IC301 8-759-822-09 IC LB1641
IC303 8-759-362-47 IC CXD8567AM
IC304 8-759-710-59 IC NJM4580D-D (AEP,G)
IC305 8-749-921-12 IC GP1F32T (DIGITAL OUT)
IC401 8-759-634-51 IC M5218AP (AEP,G)
IC401 8-759-971-80 IC AD712JN (UK)
IC501 8-759-634-51 IC M5218AP (AEP,G)
IC501 8-759-971-80 IC AD712JN (UK)
IC920 8-759-636-16 IC M51957AL
IC930 8-759-710-59 IC NJM4580D-D
IC931 8-759-634-51 IC M5218AP (AEP,G)
IC931 8-759-710-59 IC NJM4580D-D (UK)
< JACK >
J401 1-770-719-11 JACK, PIN 2P (LINE OUT)(AEP,G)
J401 1-774-727-11 JACK, PIN 2P (LINE OUT)(UK)
< COIL >
L301 1-410-322-11 INDUCTOR 3.3uH
L302 1-410-322-11 INDUCTOR 3.3uH
L305 1-249-401-11 CARBON 47 5% 1/4W
L306 1-410-322-11 INDUCTOR 3.3uH
L401 1-410-322-11 INDUCTOR 3.3uH
L501 1-410-322-11 INDUCTOR 3.3uH
L901 1-412-473-41 INDUCTOR 0uH
L902 1-412-473-41 INDUCTOR 0uH
< TRANSISTOR >
Q301 8-729-029-56 TRANSISTOR DTA144ESA
