Sony CDR-W66 - Specifications

36
Specifications
Playable discs: CD/CD-R/CD-RW
Recordable discs: CD-R/CD-RW(for music and
data use)
Number of channels: 2-channel stereo
Frequency characteristics*:20 to 20,000 Hz, (
0
dB)
-1
S/N ratio*: 98 dB (play)
92 dB (record, A-weighted)
Distortion factor*: 0.01% or less (1 kHz to _20 dB FS,
20 kHz LPF during record and
play)
* Measured values during analog input/output and
SBM function OFF
Sampling rate converter
COAXIAL/OPTICAL : 32 k, 44.1 k, 48 kHz
AES/EBU : 32 k to 96 kHz
AES/EBU output (sampling rate converter) external
synchronous frequency
32 k to 96 kHz
Analog (unbalance) input
Terminal type: Phono jack
Input impedance: 47 kZ
Reference level: _4 dBu (REC LEVEL=5, input
level for full-scale –12 dB)
ANALOG (balance) input
Terminal type: XLR-3-31 or its equivalent
Input impedance: 30 kZ or more
Reference level: +4 dBu (REC LEVEL=5, input
level for full-scale –20 dB during
shipment from the factory)
Maximum level: +24 dBu
DIGITAL (AES/EBU) input
Terminal type: XLR-3-31 or its equivalent
Input impedance: 110 kZ
Format: AES/EBU
De-emphasis: Automatic discrimination (15/50
µsec)
DIGITAL (COAXIAL) input
Terminal type: Phono jack
Input impedance: 75 Z
Reference signal level: 0.5 Vp-p ±20%
Format: Consumer IEC60958
DIGITAL (OPTICAL) input
Terminal type: Square OPTICAL
Format: Consumer IEC60958
ANALOG (unbalance) output
Terminal type: Phono jack
Load impedance: 10 kZ or more
Maximum level: +8 dBu (full-scale signal
generation during shipment from
the factory)
ANALOG (balance) output
Terminal type: XLR-3-32 or its equivalent
Load impedance: 600 Z or more
Maximum level: +24 dBu (full-scale signal
generation during shipment from
the factory)
DIGITAL (AES/EBU) output
Terminal type: XLR-3-32 or its equivalent
Format: AES/EBU
DIGITAL(COAXIAL) output
Terminal type: Phono jack
Load impedance: 75 Z
Reference signal level: 0.5 Vp-p (at 75 Z)
Format: Consumer IEC60958
DIGITAL (OPTICAL) output
Terminal type: XLR-3-31 or its equivalent
Rated output: – 18dBm
OPTICAL wavelength: 660nm
Format: Consumer IEC60958
Headphones output
Terminal type: Stereo standard jack
Output level: 0 to 10mW
Load impedance: 32 Z
WORD SYNC input
Terminal type: BNC type
Impedance: 75 Z (with ON/OFF switch)
Input level: TTL compatible
DUPLICATE terminal: DIN 8-pin female (For signal
wiring details, refer to page 29.)
Control-S input terminal: Mini jack
KEYBOARD terminal: Mini DIN 6-pin female
PARALLEL remote terminal:
D-sub 9-pin female
RS-232C terminal: D-sub 9-pin male
0 dBu = 0.775 V
Power requirements:
Where purchased Power requirements
U.S.A. and Canada 120V AC,60Hz
Other countries 230V AC, 50/60Hz
Power consumption: 26W
Dimensions(approx.): 482 × 88 × 290 mm
(19 × 3
1
/2 × 11
3
/8 in.)
(w/h/d, Including projecting
parts)
Mass(approx.): 5.2 kg (11 lbs 8 oz)
Operating temperature: +5 to +35 dC
Storage temperature: _5 to +60 dC
Accessories: Operating instructions (1)
RM-CW1 remote control (1)
R6 (size AA) batteries (2)
Control-S connector cord(1)
In the interests of improvement, specifications and
dimensions may be subject to change without notice.
