• Waveforms
– RF Board –
1 IC11 #£ (RF O)
500 mV/DIV, 500 ns/DIV
2 IC11 2 (FEI)
50 mV/DIV, 1 µs/DIV
3 IC11 $¶ (TEI)
200 mV/DIV, 500 µs/DIV
2 IC101 #§ (V16M)
3 IC101 %º (LRCK)
4 IC101 %¢ (BCKO)
5 IC101 &¢ (WFCK)
6 IC101 *ª (XTAI)
7 IC201 #¡ (EXTAL)
1.4 Vp-p
Approx.
110 mVp-p
Approx.
280 mVp-p
– MAIN Board (1/2) –
1 IC101 @¶ (MDP)
2.5 Vp-p
7.6
µ s
6.5 Vp-p
119 ns
6.2 Vp-p
22.7
µ s
6.5 Vp-p
474 ns
136 µ s
5.8 Vp-p
6.2 Vp-p
59.4 ns
4.9 Vp-p
124 ns
